Dahua Technology IPC-HDBW3241R-ZS 2MP IR Vari-Focal WizSense IP Dome Camera

Technical Specification

This product model is not available in this region

Dahua Technology IPC-HDBW3241R-ZS 2MP IR Vari-Focal WizSense IP Dome Camera

Features:

Make: Dahua Technology
Model code: IPC-HDBW3241R-ZS
Series: WizSense 3 Series
Chip Inch Size: 1/2.8
Color Type: Color / Monochrome

Additional info:

2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition Outputs max. 2MP (1920 × 1080)@30 fps H.265 codec, high compression rate, low bit rate Built-in IR LED, max. IR distance: 40 m ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human) Abnormality detection: Motion detection, video tampering, scene changing, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection Supports max. 256 G Micro SD card 12V DC/POE power supply IP67, IK10 protection SMD (Smart Motion Detection) Plus

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Dahua Technology
Manufacturer	Dahua Technology USA Inc.
Category	Video Surveillance>IP Dome cameras
Model code	IPC-HDBW3241R-ZS
Series	WizSense 3 Series
Chip Inch Size	1/2.8
Color Type	Color / Monochrome
Resolution TVL	2 MP
HD	Yes
Megapixel	Yes
Dome Type	Static
Sensitivity lux	0 ~ 0.0002
Indoor/Outdoor	Outdoor
Digital (DSP)	Yes
Mount Type	Wall, Pole, Ceiling, In-ceiling
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: < 8 W
Focal length	2.7 ~ 13.5 mm
Compression	H.265; H.264; H.264H; H.264B; MJPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/3 s ~ 1/100000 s
S/ N (Signal/ Noise) Ratio dB	> 56
Signal Mode	NTSC, PAL
Built-in IR LED	Yes
Network Properties	Interface: RJ-45 (10/100 Base-T) Network Protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP Image Frame Rate: 30 fps Inclusive DVR/ Web Server: Micro SD card
Physical Specifications	Dimensions mm: 122 x 89 Weight g: 492
Environmental Specifications	Operating Temp ^oC: -30 ~ 60 C (-22 ~ 140 F) Operating Humidity %: < 95 Protection: IP67, IK10
Additional info	2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition Outputs max. 2MP (1920 × 1080)@30 fps H.265 codec, high compression rate, low bit rate Built-in IR LED, max. IR distance: 40 m ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human) Abnormality detection: Motion detection, video tampering, scene changing, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection Supports max. 256 G Micro SD card 12V DC/POE power supply IP67, IK10 protection SMD (Smart Motion Detection) Plus
