IDIS 5MP Multi-Directional AI Security Camera
Product Profile
The DC-U6K31WRA is a multi-directional surveillance camera designed for demanding environments, featuring a 1/2.8" CMOS sensor that delivers 5MP (2592 × 1944) resolution for clear, wide-area monitoring.
A motorized vari-focal lens enables remote focus and zoom adjustment, while 120dB True WDR ensures visibility in challenging lighting. Integrated IR LEDs provide illumination up to 25 metres for reliable low-light and nighttime performance.
The integrated Intelligent Deep Learning Analytics (IDLA) engine enables accurate classification of humans, vehicles and faces, supporting intrusion and loitering detection.
Built for security and durability, the camera is FIPS 140-3 Level 3 compliant and certified to IP67, IK10 and NEMA 4X standards, operating in temperatures from -40°C to +55°C.
It supports H.265 and Intelligent Codec technologies for efficient bandwidth and storage use, integrates with DirectIP NVR systems, supports ONVIF Profile S/T, and uses PoE (IEEE 802.3at Class 4) for simplified deployment.
Key features:
- 4-channel multi-directional camera
- 5MP (2592 × 1944) resolution, 1/2.8" CMOS sensor
- Motorized vari-focal lens with remote focus and zoom
- 120dB True WDR
- IR illumination up to 25m (82ft)
- IDIS Deep Learning Analytics (IDLA)
- H.265 and Intelligent Codec support
- DirectIP NVR compatibility
- PoE (IEEE 802.3at Class 4)
- FIPS 140-3 Level 3 compliant
Technical Specification
| Make | IDIS |
|---|---|
| Manufacturer | IDIS |
| Category | Video Surveillance>IP Dome cameras |
| Model code | DC-U6K31WRA |
| Chip Inch Size | 1/2.8 |
| Color Type | Color / Monochrome |
| Resolution TVL | 5 MP |
| Megapixel | Yes |
| Sensitivity lux | COLOR : 0.1 lux @ F1.8 B/W : 0 lux (IR LED ON) |
| Dome Type | Static |
| Digital (DSP) | Yes |
| Indoor/Outdoor | Outdoor |
| Mount Type | Wall, Ceiling, Pole, Corner |
| Electrical Specifications |
Voltage: PoE Power Consumption: 21 W |
| Focal length | 3.3 ~ 7.02 mm |
| Compression | H.265, H.264 (MP), M-JPEG |
| White Balance | Yes |
| Electronic Shutter range | Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Built-in IR LED | Yes |
| Network Properties |
Interface: RJ45 (10/100/1000BASE-T) Network Protocols: DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 Image Frame Rate: 30 ips Inclusive DVR/ Web Server: Micro SD/SDHC/SDXC |
| Physical Specifications |
Dimensions mm: 258 x 112 Weight g: 2,800 |
| Environmental Specifications |
Operating Temp oC: -40 ~ 55 C (-40 ~ 131 F) Operating Humidity %: 0 ~ 90 Protection: IP67, IK10 |
| Additional info |
|
