Messoa NDF820-HN5-MES Color/Monochrome Fixed Indoor Dome Network Camera

Technical Specification

Features:

Make: Messoa
Model code: NDF820-HN5-MES
Chip Inch Size: 1/3
Color Type: Color / Monochrome
Resolution TVL: 1920 x 1080 pixels

Additional info:

Messoa NDF820-HN5-MES is a color/monochrome fixed indoor dome network camera designed to show you extremely detailed images. It features Lumii™ technology that significantly increases light sensitivity to deliver crisp image in the dark. With PoE capability it uses a single cable to transmit power and data at the same time.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Messoa
Manufacturer	MESSOA Technologies Inc.
Model code	NDF820-HN5-MES
Chip Inch Size	1/3
Color Type	Color / Monochrome
Resolution TVL	1920 x 1080 pixels
HD	Yes
Dome Type	Static
Sensitivity lux	0.1
Digital (DSP)	Yes
Indoor/Outdoor	Indoor
Electrical Specifications	Voltage: 12 V DC/PoE Power Consumption: 5 W
Focal length	4mm
Compression	H.264 / MPEG4 / Motion
Back Light Compensation	Yes
White Balance	Yes
Electronic Shutter range	1/10000 ~ 1/3.7s
Signal Mode	NTSC
Built-in IR LED	Yes
Video Output	1.0Vp-p, 75 ohm, BNC
Network Properties	Interface: 10BASE-T/100BASE-TX, RJ-45 Network Protocols: IPv4, TCP/IP, UDP, HTTP, SMTP, DNS, DHCP, NTP, FTP, RTP, RTSP, ICMP, UPnP Image Frame Rate: 15 fps
Physical Specifications	Dimensions mm: 138 x 101 Weight g: 1,130
Environmental Specifications	Operating Temp ^oC: -10 ~ +50 C (14 ~ 122 F) Operating Humidity %: 10 ~ 90
System Requirments	Web Browser: IE browser 6.0 or above
Additional info	Messoa NDF820-HN5-MES is a color/monochrome fixed indoor dome network camera designed to show you extremely detailed images. It features Lumii™ technology that significantly increases light sensitivity to deliver crisp image in the dark. With PoE capability it uses a single cable to transmit power and data at the same time.
Download PDF version Download PDF version
