IDIS DC-D4248HRA 2MP IR AI IP Dome Camera

Technical Specification

Features:

Make: IDIS
Model code: DC-D4248HRA
Series: DC-D4000 Series
Chip Inch Size: 1/2.8
Color Type: Color / Monochrome

Additional info:

2MP (1920x1080) Resolution PoE (IEEE 802.3af Class 3) IR LED (50 m/ 164ft (6 ea)) micro SD/SDHC/SDXC Alarm in / out Audio in / out IK10, IP67 IDIS Deep-Learning Analytics (IDLA) Easy Installation with DirectIP NVR

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	IDIS
Manufacturer	IDIS
Category	Video Surveillance>IP Dome cameras
Model code	DC-D4248HRA
Series	DC-D4000 Series
Chip Inch Size	1/2.8
Color Type	Color / Monochrome
Resolution TVL	2 MP
Megapixel	Yes
Sensitivity lux	Color : 0.1 lux @ F1.4; B/W : 0 lux (IR LED ON)
Digital (DSP)	Yes
Mount Type	Wall, Ceiling, Pole, Corner, Flush
Electrical Specifications	Voltage: PoE, 12 V DC Power Consumption: 12 V DC : 13.2 W; PoE : 8.3 W
Focal length	7 ~ 22 mm
Compression	H.265, H.264 (MP) M-JPEG
White Balance	Yes
Electronic Shutter range	1/30 ~ 1/10,000
Built-in IR LED	Yes
Network Properties	Interface: RJ45 (10/100BASE-T) Network Protocols: DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2 Image Frame Rate: 30 fps / 60 fps Inclusive DVR/ Web Server: Micro SD/SDHC/SDXC
Physical Specifications	Dimensions mm: 155 x 104 Weight g: 985
Environmental Specifications	Operating Temp ^oC: -40 ~ 60 C (-40 ~ 140 F) Operating Humidity %: 0 ~ 90 Protection: IP67, IK10
Additional info	2MP (1920x1080) Resolution PoE (IEEE 802.3af Class 3) IR LED (50 m/ 164ft (6 ea)) micro SD/SDHC/SDXC Alarm in / out Audio in / out IK10, IP67 IDIS Deep-Learning Analytics (IDLA) Easy Installation with DirectIP NVR
