Four Ways to Power Security in Large Sites and Open Areas

Features:

Make: Hikvision
Model code: DS-2SF8C442MXS-DLW(24F0)(P3)
Series: TandemVu PTZ cameras
Chip Inch Size: 1/1.8
Color Type: Color / Monochrome

Additional info:

Captures a large area and great details at the same time High quality imaging with 4 MP resolution for both panoramic channel and PTZ channel 24/7 colorful imaging and excellent low-light performance with DarkFighter technology Panoramic channel tilt adjustable from 7° to 17° Secures an expansive area with 42 × optical zoom and 16 × digital zoom Expansive night view with up to 30 m white light distance and 300 m IR distance Supports deep learning functions Water and dust resistant (IP67) and vandal resistant (IK10)

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Hikvision
Manufacturer	Hikvision USA Inc.
Category	Video Surveillance>IP Dome cameras
Model code	DS-2SF8C442MXS-DLW(24F0)(P3)
Series	TandemVu PTZ cameras
Chip Inch Size	1/1.8
Color Type	Color / Monochrome
Resolution TVL	4MP
Megapixel	Yes
Sensitivity lux	0.0001 ~ 0.0005
Dome Type	PTZ
Pan Speed ^o/ sec	Configurable from 0.1° to 160°/s, preset speed: 240
Tilt Speed ^o/ sec	Configurable from 0.1° to 120°/s, preset speed 200
Mount Type	Wall, Pole, Pendant
Electrical Specifications	Voltage: 36 V DC
Focal length	[Panoramic channel] 2.8 mm, [PTZ channel] 5.9 to 247.8 mm
Presets	300
Compression	H.265+/H.265/H.264+/H.264 /MJPEG
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/1 s ~ 1/30000 s
S/ N (Signal/ Noise) Ratio dB	≥ 52
Zoom Ratio	42× optical zoom
Network Properties	Interface: 1 RJ45 100M self-adaptive Ethernet port Network Protocols: IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP Image Frame Rate: 25/30fps
Physical Specifications	Dimensions mm: Ø290 x 453.2 Weight g: 11,500
Environmental Specifications	Operating Temp ^oC: -40 ~ +70 C (-40 ~ +158 F) Operating Humidity %: < 95 Protection: IP67
System Requirements	Web Browser: IE 10+, Chrome 57+, Firefox 52+, Safari 12+
Additional info	Captures a large area and great details at the same time High quality imaging with 4 MP resolution for both panoramic channel and PTZ channel 24/7 colorful imaging and excellent low-light performance with DarkFighter technology Panoramic channel tilt adjustable from 7° to 17° Secures an expansive area with 42 × optical zoom and 16 × digital zoom Expansive night view with up to 30 m white light distance and 300 m IR distance Supports deep learning functions Water and dust resistant (IP67) and vandal resistant (IK10)
