- Hikvision DS-2SF8C442MXS-DLW(24F0)(P3)
Four Ways to Power Security in Large Sites and Open Areas
Technical Specification
This product model is not available in this region
Features:
- Make: Hikvision
- Model code: DS-2SF8C442MXS-DLW(24F0)(P3)
- Series: TandemVu PTZ cameras
- Chip Inch Size: 1/1.8
- Color Type: Color / Monochrome
Additional info:
Captures a large area and great details at the same time High quality imaging with 4 MP resolution for both panoramic channel and PTZ channel 24/7 colorful imaging and excellent low-light performance with DarkFighter technology Panoramic channel tilt adjustable from 7° to 17° Secures an expansive area with 42 × optical zoom and 16 × digital zoom Expansive night view with up to 30 m white light distance and 300 m IR distance Supports deep learning functions Water and dust resistant (IP67) and vandal resistant (IK10)
Read moreMake | Hikvision |
---|---|
Manufacturer | Hikvision USA Inc. |
Category | Video Surveillance>IP Dome cameras |
Model code | DS-2SF8C442MXS-DLW(24F0)(P3) |
Series | TandemVu PTZ cameras |
Chip Inch Size | 1/1.8 |
Color Type | Color / Monochrome |
Resolution TVL | 4MP |
Megapixel | Yes |
Sensitivity lux | 0.0001 ~ 0.0005 |
Dome Type | PTZ |
Pan Speed o/ sec | Configurable from 0.1° to 160°/s, preset speed: 240 |
Tilt Speed o/ sec | Configurable from 0.1° to 120°/s, preset speed 200 |
Mount Type | Wall, Pole, Pendant |
Electrical Specifications | Voltage: 36 V DC |
Focal length | [Panoramic channel] 2.8 mm, [PTZ channel] 5.9 to 247.8 mm |
Presets | 300 |
Compression | H.265+/H.265/H.264+/H.264 /MJPEG |
Auto Gain Control | Yes |
White Balance | Yes |
Electronic Shutter range | 1/1 s ~ 1/30000 s |
S/ N (Signal/ Noise) Ratio dB | ≥ 52 |
Zoom Ratio | 42× optical zoom |
Network Properties |
Interface: 1 RJ45 100M self-adaptive Ethernet port Network Protocols: IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,FTP Image Frame Rate: 25/30fps |
Physical Specifications |
Dimensions mm: Ø290 x 453.2 Weight g: 11,500 |
Environmental Specifications |
Operating Temp oC: -40 ~ +70 C (-40 ~ +158 F) Operating Humidity %: < 95 Protection: IP67 |
System Requirements | Web Browser: IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
Additional info |
|
Download PDF version Download PDF version |
