Eagle Eye Networks DB12 8MP Indoor/Outdoor IR Mini Bullet IP Camera

Technical Specification

Features:

Make: Eagle Eye Networks
Model code: DB12
Color Type: Color / Monochrome
Resolution: 8 MP
Digital (DSP): Yes

Additional info:

High performance 8MP camera with an IP67 environmental rating Indoor/outdoor waterproof mini-bullet Fixed lens 2.8mm Wide Dynamic Range Night Vision Smart IR, IR LEDs, 30m range Triple RTSP Streams Comes pre-configured to securely operate with the Eagle Eye Cloud Security VMS and Eagle Eye CameraManager Suitable for small indoor areas: stock room, lobby, hallways, elevators, IT closets, storage rooms, entrances, interview rooms

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Eagle Eye Networks
Manufacturer	Eagle Eye Networks, Inc.
Category	Video Surveillance>IP cameras
Model code	DB12
Color Type	Color / Monochrome
Resolution	8 MP
Digital (DSP)	Yes
Specialist Type	Infrared
Sensitivity Lux	0 ~ 0.01
Auto Iris	Yes
Direct Drive	Yes
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 3.5 ~ 8 W
Focal Length mm	2.8
Wide Dynamic Range	Yes
Picture Elements HxV	3840 x 2160
Network Properties	Image Frame Rate: 25 fps / 30 fps Inclusion DVR/ Web Server: Yes Interface: RJ-45 Female 10/100 Base-T
Back Light Compensation	Yes
Electronic Shutter Range	1/5s ~ 1/20000s
Mini or Compact	Yes
Y/ C (Video Output)	Built-in CVBS output
Compression Type	H.265, H.264, and MJPEG
Physical Specifications	Dimensions mm: 194 x 63 x 63 Weight g: 500
Environmental Specifications	Protection: IP67 Operating Temperature ^oC: -30 ~ 50 C (-22 ~ 122 F) Operating Humidity %: 0 ~ 90
Additional info	High performance 8MP camera with an IP67 environmental rating Indoor/outdoor waterproof mini-bullet Fixed lens 2.8mm Wide Dynamic Range Night Vision Smart IR, IR LEDs, 30m range Triple RTSP Streams Comes pre-configured to securely operate with the Eagle Eye Cloud Security VMS and Eagle Eye CameraManager Suitable for small indoor areas: stock room, lobby, hallways, elevators, IT closets, storage rooms, entrances, interview rooms
