Dahua 4MP Fixed-focal Bullet Network Camera
Pro AI series contains Face Detection, Perimeter Protection and People Counting functions.Powered by deep-learning Artificial Intelligence algorithms, significantly improved accuracy. Meanwhile, the series features starlight and smart IR technology. This series fully protected from dust and water, certified to IP67 standard.
Face Detection is a software application that automatically captures faces from within a digital image or a video frame from a video source. Dahua cameras use advanced deep learning algorithms and are trained by a large number of face data sources, enabling the camera to locate faces quickly and accurately from the video source and capture facial images.
Dahua’s Perimeter Protection functions significantly improved accuracy. Perimeter Protection reduces false alarms and decreases pixel count requirements for object detection. Perimeter Protection features custom tripwires based on object type for automation in limited access areas such as pedestrian or vehicle-only zones. This combination of advanced AI analytics and real-time alerts to a desktop or to a mobile client reduces system requirements and resources resulting in greater surveillance system efficiency.
People Counting function uses advanced image processing technology to capture depth information from within images. The camera pairs this information with deep learning algorithms to analyze and detect human bodies and track target objects in real time. The camera provides statistics for separate individuals’ entrance and exit with up to 95% counting accuracy.
Protection(IP67, wide voltage)
The camera allows for ±30% input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 6KV lightning rating provides effective protection for both the camera and its structure against lightning. Subjected and certified to rigorous dust and immersion tests (IP67) , the camera is the choice for installation in even the most unforgiving environments.
The ePoE technology of Dahua, designed internally, adopts advanced 2D-PAM3 coding modulation from physical layer, and realizes full duplex transmission over 800 meters at the speed of 10Mbps, or 300 meters at the speed of 100Mbps via Cat 5 or coaxial cable media. Besides, it supports PoE and PoC power supply technology which has greatly simplified construction and wiring. Dahua ePoE technology offer a new way to accomplish long distance transmission between IP camera and network switch. It allows more flexible surveillance system design, improves reliability and saves construction and wiring cost.
|Manufacturer||Dahua Technology USA Inc.|
|Chip Inch Size||1/1.8|
|Color Type||Color / Monochrome|
Voltage: 12 V DC, PoE
Power Consumption: <6.8W
|Focal Length mm||2.8 mm, 3.6 mm, 6.0 mm|
|Mount Type||Pole, Corner|
|Wide Dynamic Range||Yes|
|Picture Elements HxV||2688 x 1520|
Image Frame Rate: 25/30 fps, 50/60 fps
Interface: RJ-45 (10/100 Base-T)
Network Protocols: IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP ;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP ;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
|Back Light Compensation||Yes|
|Auto Gain Control||Yes|
|Electronic Shutter Range||1/3 s–1/100000 s|
|Signal Mode||PAL, NTSC|
|Compression Type||H.265,H.264,H.264B,H.264H, MJPEG (sub stream)|
Weight g: 470
Dimensions mm: 182 x 70 x 70
Operating Temperature oC: -30 ~ +60 C (-22 ~ +140 F)
|System Requirements||Web Browser: IE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12)|
|Download PDF version|
