Dahua DH-IPC-HFW2431DG-4G-SP-EAU-B 4MP IR Fixed-focal Bullet 4G Solar Power Network Camera

Technical Specification

This product model is not available in this region

Dahua DH-IPC-HFW2431DG-4G-SP-EAU-B 4MP IR Fixed-focal Bullet 4G Solar Power Network Camera

Features:

Make: Dahua Technology
Model code: DH-IPC-HFW2431DG-4G-SP-EAU-B
Series: Lite series
Chip Inch Size: 1/3
Color Type: Color / Monochrome

Additional info:

4-MP 1/3" CMOS image sensor, low luminance, and high definition image. Outputs max. 4 MP (2688 × 1520) @25/30 fps. H.265 codec, high compression rate, ultra-low bit rate. Built-in warm light/IR LED. Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked. Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks. Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature. Built-in 8 GB eMMC memory chip that protects key records from being lost. Supports solar power, making it ideal for use in locations that have exposure to sunlight. Standalone with built-in solar panel and battery, battery cycle life can last up to 10 days at the rate of 1-hour remote live view per day. Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access. Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Dahua Technology
Manufacturer	Dahua Technology USA Inc.
Category	Video Surveillance>IP cameras
Model code	DH-IPC-HFW2431DG-4G-SP-EAU-B
Series	Lite series
Chip Inch Size	1/3
Color Type	Color / Monochrome
Resolution	4MP
Sensitivity Lux	0.01 Lux@F1.6 (Color,30IRE), 0.001 Lux@F1.6 (B/W,30IRE), 0 lux (Illuminator on)
Electrical Specifications	Voltage: MicroUSB / 5 VDC Power Consumption: Max. (4G pulling stream+IR+speaker+warning light): 4 W
Motion Activated	Yes
Focal Length mm	2.8 mm; 3.6 mm; 6 mm
Mount Type	Wall, Pole
Wide Dynamic Range	Yes
Network Properties	Image Frame Rate: 25/30 fps Interface: RJ-45 (10/100 Base-T) Network Protocols: IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter Range	Auto/Manual 1/3 s–1/100,000 s
S/ N (Signal/ Noise) Ratio dB	>56
Compression Type	H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Physical Specifications	Weight g: 190 Dimensions mm: 230 x 150 x 2
Environmental Specifications	Protection: IP67, IK10 Operating Temperature ^oC: -40 ~ +60 C (-40 ~ +140 F) Operating Humidity %: ≤ 95
Additional info	4-MP 1/3" CMOS image sensor, low luminance, and high definition image. Outputs max. 4 MP (2688 × 1520) @25/30 fps. H.265 codec, high compression rate, ultra-low bit rate. Built-in warm light/IR LED. Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked. Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks. Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature. Built-in 8 GB eMMC memory chip that protects key records from being lost. Supports solar power, making it ideal for use in locations that have exposure to sunlight. Standalone with built-in solar panel and battery, battery cycle life can last up to 10 days at the rate of 1-hour remote live view per day. Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access. Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk
