Videotec NVX Delux-technology Corrosion-resistant Camera

Product Profile

Videotec is launching NVX, an IP FULL HD super low-light camera with high corrosion resistance. This camera incorporates the DELUX imaging and encoding technology for recording incredibly clear color video day or night.

The most important feature is the extremely sensitive light sensor that works with the DELUX technology to provide high color rendering and maximum noise reduction in night-time or very low light conditions (up to 0.006 lux, or 0.0006 lux in black and white).

Videotec’s NVX camera is super low-light Day/Night Full HD 1080p, with 30x optical zoom and 60 fps shooting speed. Images can be transmitted via network with H.264/AVC, MPEG4, MJPEG or JPEG compression, and it’s possible to have up to 3 simultaneous and independent Full HD video streams.

The NVX camera is made entirely from AISI316L stainless steel and stands out from other cameras thanks to its compact and lightweight design that, along with the simple connectors, helps installation and maintenance.

The windscreen wiper is a standard feature, as is the modular support for wall, ceiling or railing mounting.

NVX has exceptional corrosion resistance, a wide operational temperature range and IP66/IP67 protection. These features mean it is well suited to applications in marine, harbor and industrial environments – including the food industry – as well as in motorway tunnels.

Read more

Technical Specification

Make Videotec
Manufacturer Videotec
Model code NVX210XXXA
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution 1080p
Digital (DSP) Yes
Sensitivity Lux 0.0006 ~ 0.006
Auto Iris Yes
Direct Drive Yes
Electrical Specifications Voltage: 24 V AC, 24 V DC, PoE
Power Consumption: 21 W
Motion Activated Yes
Focal Length mm 4.5 ~ 135
Mount Type Wall, Ceiling
Wide Dynamic Range Yes
Network Properties Image Frame Rate: 1 ~ 60 fps
Interface: RJ45, 100 Base-TX
Auto Gain Control Yes
White Balance Yes
Electronic Shutter Range 1/1s ~ 1/10000s
Zoom Yes
Compression Type H.264/AVC, MJPEG, JPEG, MPEG4
Physical Specifications Weight g: 6200
Dimensions mm: 360 x 350 x 230
Environmental Specifications Protection: IP66/IP67/IP68/IP69
Operating Temperature oC: -40 ~ +65 C (-40 ~ +149 F)
Operating Humidity %: 10 ~ 95
HD Yes
Additional info
  • In electro-polished stainless steel AISI 316L
  • Rapid connectors
  • Camera Full HD 1080p, 30x, 60fps
  • Video compression H.264/AVC, MJPEG, JPEG and MPEG4
  • Complies with ONVIF, Profile S and Profile Q
  • Day/Night (Auto ICR: automatic removal of IR filter)
  • De-fog function
  • Up to 3 simultaneous video streams in FULL HD
  • 1 input for remote reset and 2 relay outputs
  • Integrated wiper
  • Power supply: 24Vdc/24Vac, PoE+
  • Tested and certified: from -40°C (-40°F) up to +65°C (149°F)
  • Built-in modular support
