Bosch NDE-3502-F03-P 2MP Outdoor HD Fixed IP Micro Dome Camera

Technical Specification

Features:

Make: Bosch
Model code: NDE-3502-F03-P
Series: FLEXIDOME IP micro 3000i - outdoor
Chip Inch Size: 1/2.8
Color Type: Color / Monochrome

Additional info:

1080p resolution Fully configurable H.265 multi-streaming Built-in Essential Video Analytics to trigger relevant alerts and quickly retrieve data Tamper and motion detection Conforms to the ONVIF Profile S, ONVIF Profile G and ONVIF Profile T specifications High Dynamic Range (120 dB) for challenging bright and dark scenes

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Bosch
Manufacturer	Bosch Security Systems
Category	Video Surveillance>IP Dome cameras
Model code	NDE-3502-F03-P
Series	FLEXIDOME IP micro 3000i - outdoor
Chip Inch Size	1/2.8
Color Type	Color / Monochrome
Resolution TVL	2 MP
HD	Yes
Megapixel	Yes
Sensitivity lux	0.05 ~ 0.1
Dome Type	Static
Indoor/Outdoor	Outdoor
Digital (DSP)	Yes
Mount Type	Surface
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 3.1 ~ 3.5 W
Focal length	2.3 mm, 2.8 mm
Compression	H.265; H.264; M- JPEG
Back Light Compensation	Yes
White Balance	Yes
Electronic Shutter range	1/25[30] ~ 1/15000
S/ N (Signal/ Noise) Ratio dB	> 55
Video Output	CVBS : 1.0 Vp-p / 75Ω composite
Network Properties	Interface: RJ45 connector, 10/100 Base-T Network Protocols: IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP/RTCP, IGMP V2/V3, ICMP, ICMPv6, RTSP, FTP, ARP, DHCP, APIPA (Auto-IP, link local address), NTP (SNTP), SNMP (V1, V3, MIB-II), 802.1x, DNS, DNSv6, DDNS (DynDNS.org, selfHOST.de, noip.com), SMTP, iSCSI, UPnP (SSDP), Di Image Frame Rate: 25 fps / 30 fps Inclusive DVR/ Web Server: microSDHC / microSDXC
Physical Specifications	Dimensions mm: 121 x 69 Weight g: 456
Environmental Specifications	Operating Temp ^oC: -30 ~ 50 C (-22 ~ 122 F) Protection: IP66, IK10
Additional info	1080p resolution Fully configurable H.265 multi-streaming Built-in Essential Video Analytics to trigger relevant alerts and quickly retrieve data Tamper and motion detection Conforms to the ONVIF Profile S, ONVIF Profile G and ONVIF Profile T specifications High Dynamic Range (120 dB) for challenging bright and dark scenes
