Bosch NDC-455V03-11P Dome Camera With Built-in Video Motion Detection

Technical Specification

Features:

Make: Bosch
Model code: NDC-455V03-11P
Chip Inch Size: 1/3
Color Type: Color
Resolution TVL: 540

Additional info:

FlexiDome IP cameras are progressive scan CCD colour cameras in a compact, high-impact rated, vandal-resistant housing. They can tri-stream video simultaneously - on two H.264 streams and one M-JPEG stream. Features such as multicasting, internet streaming and iSCSI recording are fully supported. FlexiDome IP cameras have built-in video motion detection and additional processing power for video content analysis systems.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Bosch
Manufacturer	Bosch Security Systems
Category	Video Surveillance>Dome cameras
Model code	NDC-455V03-11P
Chip Inch Size	1/3
Color Type	Color
Resolution TVL	540
Sensitivity lux	0.30 @ F1.2
Dome Type	Continuous Rotation
Indoor/Outdoor	Indoor/Outdoor
Mount Type	Flush
Electrical Specifications	Voltage: 12 V DC / 24 V AC
Focal length	2.8 ~ 10
Rotation Angles^o	360 pan, 90 tilt
Compression	H.264, M-JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
S/ N (Signal/ Noise) Ratio dB	50
Synchronisation	Internal, Line-lock
Signal Mode	PAL
Network Properties	Interface: STP, 10/100 Base-T, auto-sensing, half/full duplex Network Protocols: RTP, Telnet, UDP, TCP, IP, HTTP, HTTPS, FTP, DHCP Image Frame Rate: 1 ~ 50
Physical Specifications	Weight g: 670
Environmental Specifications	Operating Temp ^oC: -20 ~ +50 Operating Humidity %: 5 ~ 93 Protection: IP66
Additional info	FlexiDome IP cameras are progressive scan CCD colour cameras in a compact, high-impact rated, vandal-resistant housing. They can tri-stream video simultaneously - on two H.264 streams and one M-JPEG stream. Features such as multicasting, internet streaming and iSCSI recording are fully supported. FlexiDome IP cameras have built-in video motion detection and additional processing power for video content analysis systems.
