Axis Communications AXIS M1014 1/4-inch 1MP HDTV 720p Network Camera With Edge Storage

Technical Specification

Features:

Make: Axis Communications
Model code: AXIS M1014
Series: M10 Series
Chip Inch Size: 1/4
Resolution: 1 MP

Additional info:

AXIS M1014 network camera supports edge storage, which includes support for storage on microSDHC cards as well as recording to network shares such as Network-Attached Storage (NAS). Video intelligence includes video motion detection and active tampering alarm. Together with AXIS camera companion, AXIS M1014 offers a very price competitive solution. The network camera is ideal for securing locations such as small businesses, boutiques, restaurants, hotels or residences. It offers superior video quality in its class at 30 frames per second in 1 megapixel or HDTV 720p resolution. It offers easy and flexible installation.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Axis Communications
Manufacturer	Axis Communications
Category	Video Surveillance>IP cameras
Model code	AXIS M1014
Series	M10 Series
Chip Inch Size	1/4
Resolution	1 MP
Digital (DSP)	Yes
Specialist Type	Network
Sensitivity Lux	1.2 ~ 100000
Auto Iris	Yes
Direct Drive	Yes
Electrical Specifications	Voltage: 4.9 ~ 5.1 V DC Power Consumption: 6.5 W
Motion Activated	Yes
Focal Length mm	2.8
Wide Dynamic Range	Yes
Picture Elements HxV	1280 x 800
Network Properties	Image Frame Rate: 30 fps Inclusion DVR/ Web Server: Yes Interface: RJ45 10BASE-T/100BASE-TX Network Protocols: IPv4/v6, HTTP, HTTPSb, SSL/TLSb, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Back Light Compensation	Yes
White Balance	Yes
Electronic Shutter Range	1/8000 ~ 1/6s
Compression Type	H.264 Main Profile (MPEG-4 Part 10/AVC), Motion JPEG
Physical Specifications	Weight g: 110
Environmental Specifications	Operating Temperature ^oC: 0 ~ 40 C (32 ~ 104 F) Operating Humidity %: 20 ~ 80
HD	Yes
Additional info	AXIS M1014 network camera supports edge storage, which includes support for storage on microSDHC cards as well as recording to network shares such as Network-Attached Storage (NAS). Video intelligence includes video motion detection and active tampering alarm. Together with AXIS camera companion, AXIS M1014 offers a very price competitive solution. The network camera is ideal for securing locations such as small businesses, boutiques, restaurants, hotels or residences. It offers superior video quality in its class at 30 frames per second in 1 megapixel or HDTV 720p resolution. It offers easy and flexible installation.
