Vivotek PZ8111/21 Pan/tilt/zoom Network Camera For Indoor Surveillance

Technical Specification

Features:
  • Make: VIVOTEK
  • Model code: PZ8111/21
  • Series: WISENET X SERIES
  • Chip Inch Size: 1/4
  • Color Type: Color / Monochrome
Read more
Additional info:

Vivotek PZ8111/21 is a network camera with 10x optical zoom and pan/tilt functionality. The camera is designed for indoor surveillance applications such as retail stores, offices or banks. With flexible 300-degree pan and 135-degree tilt, it can give users more comprehensive control over the monitored site.

Read more
Make VIVOTEK
Manufacturer VIVOTEK
Model code PZ8111/21
Series WISENET X SERIES
Chip Inch Size 1/4
Color Type Color / Monochrome
Digital (DSP) Yes
Specialist Type PTZ
Sensitivity Lux 0.05
Auto Iris Yes
Electrical Specifications Voltage: 12 V DC
Power Consumption: 11.16 W
Motion Activated Yes
Focal Length mm 4.2 ~ 42
Network Properties Image Frame Rate: 30 fps
Interface: 10/100 Mbps Ethernet, RJ-45
Network Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, and 802.1X
Software: 32-CH ST7501 recording software
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter Range 1/50 ~ 1/10,000s
Signal Mode NTSC
Zoom Yes
Compression Type H.264, MJPEG, MPEG-4
Physical Specifications Weight g: 391
Dimensions mm: 105 x 124
Environmental Specifications Operating Temperature oC: 0 ~ 50 C (32 ~ 122 F)
Operating Humidity %: 20 ~ 80
System Requirements Operating System: Microsoft Windows 7/Vista/XP/2000
Web Browser: Mozilla Firefox, Internet Explorer 6.x or above
Additional info Vivotek PZ8111/21 is a network camera with 10x optical zoom and pan/tilt functionality. The camera is designed for indoor surveillance applications such as retail stores, offices or banks. With flexible 300-degree pan and 135-degree tilt, it can give users more comprehensive control over the monitored site.
