Messoa NID335-P5-MES 1/3-inch True Day/night IP Dome Camera

Technical Specification

Features:

Make: Messoa
Model code: NID335-P5-MES
Chip Inch Size: 1/3
Color Type: True Day / Night
Resolution TVL: 3 MP

Additional info:

The NID335-P5-MES is a professional 3-megapixel IP dome camera designed for detail-demanding indoor surveillance, delivering high quality live view and recorded footage with superior high definition video up to 30fps. A true day/night camera, the NID335-P5-MES features improved sensitivity backed by proprietary Lumii™ Low Light Technology and 3DNR to provide unprecedented image clarity under the cover of darkness. The NID335-P5-MES also features installation-facilitating motorized zoom with auto focus, as well as the enhanced Ultra WDR and local storage to make it a versatile solution for diverse indoor surveillance applications.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Messoa
Manufacturer	MESSOA Technologies Inc.
Category	Video Surveillance>IP Dome cameras
Model code	NID335-P5-MES
Chip Inch Size	1/3
Color Type	True Day / Night
Resolution TVL	3 MP
HD	Yes
Megapixel	Yes
Dome Type	Static
Sensitivity lux	0.02
Indoor/Outdoor	Indoor
Digital (DSP)	Yes
Mount Type	Surface
Electrical Specifications	Voltage: 12 V DC Power Consumption: 7 W
Focal length	3 ~ 9 mm
Rotation Angles^o	0 ~ 350
Compression	H.264 / MJPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/10,000 ~ 1/7.5s
Signal Mode	PAL
Network Properties	Interface: 10Base-T/100Base-TX Ethernet, RJ-45 Network Protocols: ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: 125 x 106 Weight g: 500
Environmental Specifications	Operating Temp ^oC: -10 ~ +50 C (-14 ~ +122 F) Operating Humidity %: 0 ~ 90
System Requirements	Web Browser: Internet Explorer, Chrome, Firefox, Safari
Additional info	The NID335-P5-MES is a professional 3-megapixel IP dome camera designed for detail-demanding indoor surveillance, delivering high quality live view and recorded footage with superior high definition video up to 30fps. A true day/night camera, the NID335-P5-MES features improved sensitivity backed by proprietary Lumii™ Low Light Technology and 3DNR to provide unprecedented image clarity under the cover of darkness. The NID335-P5-MES also features installation-facilitating motorized zoom with auto focus, as well as the enhanced Ultra WDR and local storage to make it a versatile solution for diverse indoor surveillance applications.
