Messoa NID321-N5-MES 1MP True Day/Night Indoor IP Dome Camera

Technical Specification

Features:
  • Make: Messoa
  • Model code: NID321-N5-MES
  • Series: WatchMaster IP Ultra 3000
  • Chip Inch Size: 1/4
  • Color Type: True Day / Night
Read more
Additional info:

Messoa NID321-N5-MES is a 1MP true day/night indoor IP dome camera designed for detail-demanding indoor surveillance, delivering high quality live view and recorded footage with superior high definition video up to 30fps. It also features easy, flexible installation with 3-axis lens adjustment, as well as the enhanced Ultra WDR and local storage to make it a versatile solution for diverse indoor surveillance applications.

Read more
Make Messoa
Manufacturer MESSOA Technologies Inc.
Model code NID321-N5-MES
Series WatchMaster IP Ultra 3000
Chip Inch Size 1/4
Color Type True Day / Night
Resolution TVL 1 MP
Megapixel Yes
Dome Type Static
Sensitivity lux 0.004
Indoor/Outdoor Indoor
Digital (DSP) Yes
Electrical Specifications Voltage: 12 V DC/PoE
Power Consumption: 6 W
Focal length 2.3 ~ 10mm
Compression H.264/MJPEG
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/10,000 ~ 1/7.5s
Signal Mode NTSC
Built-in IR LED Yes
Network Properties Interface: 10BASE-T/100BASE-TX, RJ-45
Network Protocols: ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X
Image Frame Rate: 30 fps
Inclusive DVR/ Web Server: SDXC/SDHC card
Physical Specifications Dimensions mm: 125 x 106
Weight g: 500
Environmental Specifications Operating Temp oC: -10 ~ +50 C (14 ~ 122 F)
Operating Humidity %: 90
System Requirments Web Browser: Internet Explorer, Chrome, Firefox, Safari
Additional info Messoa NID321-N5-MES is a 1MP true day/night indoor IP dome camera designed for detail-demanding indoor surveillance, delivering high quality live view and recorded footage with superior high definition video up to 30fps. It also features easy, flexible installation with 3-axis lens adjustment, as well as the enhanced Ultra WDR and local storage to make it a versatile solution for diverse indoor surveillance applications.
