Eneo Launches New Product Generation With H.264

Product Profile

The new GL Generation has been boosted with the H.264 codec and can now apply dual streaming technology for simultaneous transmission and archiving of two fully independent video streams - each with its own configuration and different transmission rates, resolution and quality - in H.264 and MJPEG. This allows flexible utilisation of the varying bandwidths in networks as well as the available memory. The GL Series product range comprises IP Domes and Box Cameras, Servers and Encoders as well as the free GL CMS Manager Video Management Software.

Noise suppression and a horizontal image resolution of 540 TV lines allow the latest GL Generation Dome and Box Network Cameras to produce first-class image quality. Fitted with a 1/3" Super HAD CCD Sensor and integral motion detector, the cameras deliver a transfer rate of 25 fps over all resolution levels.

The compatible GL Series Network Video Servers are offered as a Box Type solution or alternatively as an Encoder Board. The bofard is sized only 42x42x25 millimetres with equal network capability to the Box Type version. Both are a 1-channel video server with Power-over-Ethernet (PoE) and an integral web server accessible from a standard browser. The maximum image resolution (D1) is 720x576 pixels. Both servers offer multilevel password protection, an IP filter (access rights only for defined IP addresses) or HTTPS (data encryption). Management software compatibility is given by Symphony from Aimetis, Zelaris IP from eneo, Observer from NetAvis, Milestone XProtect Corporate as well as GL CMS Manager from eneo.

The free viewer and management software GL CMS Manager from eneo simultaneously receives and stores up to 16 video sources, it features event triggered recording options as well as automatic alarm image display.

By the way, GL product family adaptation to the new ONVIF standard will be phased in from early next year.

Read more

Technical Specification

Make eneo
Manufacturer eneo
Model code GLC-1601
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution 510
Digital (DSP) Yes
Specialist Type Infrared
Sensitivity Lux 0.6
Lens Mount C/CS
Electrical Specifications Voltage: 12 V DC / PoE
Power Consumption: 6 W
Motion Activated Yes
Picture Elements HxV 752 x 582
Network Properties Image Frame Rate: 25 fps
Inclusion DVR/ Web Server: DVR
Interface: 10/100Base-TX, RJ-45
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter Range 1/50 ~ 1/100,000
Signal Mode PAL
Y/ C (Video Output) 1 Vp-p, Composite, 75 Ohms, BNC
Compression Type M-JPEG, MPEG-4
Physical Specifications Weight g: 360
Environmental Specifications Operating Temperature oC: 0 ~ 50
System Requirements Web Browser: Microsoft Internet Explorer 6.0
Additional info

Day & night network camera with integrated web server. Removable IR cut filter. Simultaneous video and audio signal transmission. Email and FTP transmission of important events. Integrated Activity Detection. Supports various network environments. Alarm in/output, audio output. Upgrade via SD Card, USB Interface and network.
