CIVINTEC CT9-W-Q-2R-UV-D Access Control Terminal
Technical Specification
- Make: CIVINTEC
- Model code: CT9-W-Q-2R-UV-D
- Series: CT9 PRO-D
- Standalone/ Networked/ PC: Standalone / Networked
- Reader Type: Wiegand
3.5" touchscreen with customisable background image and real time message intuitive for visitor Support mobile credential by using personal mobile phone and smart watch via BLE, NFC and HID® mobile virtual card multi-technologies With embedded QR code scanner and dynamic QR code generator for temporary visitor access control Support DESFire EV1/EV2/EV3 encrypted smart cards and HID® Seos, iCLASS smart cards Support RJ45 port WiFi Support HTTP & HTTPs encrypted communication protocol Support both of local offline and online mode under server remote control in real time Wiegand input for APB secure slave access control reader With 2 relay output separately controlled by server Support software and firmware remote upgrade Protected by IP65 waterproof and UV-resistance for outdoor under strong UV ray Cost effective customization service from hardware, software to firmware
Read more| Make | CIVINTEC |
|---|---|
| Manufacturer | CIVINTEC Global Co., Limited |
| Category | Access Control>Access control systems & kits |
| Model code | CT9-W-Q-2R-UV-D |
| Series | CT9 PRO-D |
| Standalone/ Networked/ PC | Standalone / Networked |
| Reader Type | Wiegand |
| c/w Cards, Tags or Fobs | Cards |
| No of Cardholders | Online - Unlimited; Offline - 10,000 |
| No/ Type of Inputs/ Outputs | 3 Inputs, 4 Outputs; 2 Relay Output |
| Keypad Included | Yes |
| Environmental Specifications |
Operating Temperature oC: -20 ~ 60 C (-4 ~ 140 F) Operating Humidity %: 0 ~ 90 Protection: IP65 |
| Electrical Specifications | Voltage: 12 ~ 24 V DC |
| Physical Specifications | Dimensions mm: 45 x 200 x 84 |
| System Requirements | Operating System: LINUX |
Product description
CIVINTEC CT9-W-Q-2R-UV-D Security Access Device
The CIVINTEC CT9-W-Q-2R-UV-D is a versatile security access device designed for seamless integration in professional settings. Equipped with advanced technology, this model supports a wide array of identification formats, including 125KHz PROx, 125KHz EM, and 13.56MHz Mifare® formats such as Classic, Ultralight®, Plus, DESFire® EV1/EV2/EV3, and NFC tags. It readily accommodates various 1D and 2D barcodes, enhancing flexibility with QR Codes, Micro QR codes, PDF417, Code 128, Code 39, and other popular formats.
Key Features
- Customizable display with real-time text, logo, and background image adjustments
- Audio management with changeable files for alerts and notifications
- Full 360° roll, with a pitch and yaw tolerance of +55°
- Connectivity via TCP/IP, 4G, WiFi, RS485, and wiegand input
- Power over Ethernet (PoE) IEEE 802.3af compliance
- Supports PIN code and mobile phone access methods
Ideal Use Cases
The CT9-W-Q-2R-UV-D is built for environments requiring robust, flexible access control solutions, such as corporate offices, manufacturing facilities, or any application that necessitates customizable display and multiple connectivity options. This device assures security professionals of reliable access management with its diverse decoding range and compatibility with existing security infrastructure.
