Axis Communications F2107-RE 5 MP discreet standard sensor
Technical Specification
- Make: Axis Communications
- Model code: F2107-RE
- Chip Inch Size: 1/2.8
- Resolution: 5MP
- Sensitivity Lux: Color: 0.25 lux
High-quality 5 MP resolution 110° horizontal field of view Rugged sensor unit with SMA connector Can be installed in vehicles and machinery IP66-/IP67-/IP6K9K-rated
Read more| Make | Axis Communications |
|---|---|
| Manufacturer | Axis Communications |
| Category | Video Surveillance>IP cameras |
| Model code | F2107-RE |
| Chip Inch Size | 1/2.8 |
| Resolution | 5MP |
| Sensitivity Lux | Color: 0.25 lux |
| Focal Length mm | 2.8 mm |
| Wide Dynamic Range | Yes |
| Electrical Specifications | Power Consumption: max 1.8 W |
| Environmental Specifications |
Protection: IP66, IP67, IP6K9K Operating Temperature oC: -40 ~ +60 C (-40 ~ +140 F) Operating Humidity %: 10 ~ 100 |
Product description
AXIS F2107-RE Standard Sensor
The AXIS F2107-RE Standard Sensor is designed for discreet installations and offers exceptional image quality with its 5 MP resolution. It provides a 110° horizontal field of view, ensuring comprehensive area coverage suitable for various security applications. Featuring a compact cylinder shape, it integrates seamlessly into environments demanding unobtrusive surveillance.
Rugged and Versatile Design
This sensor unit can withstand harsh conditions, operating efficiently in temperatures from -40 °C to 60 °C and boasting IP66, IP67, and IP6K9K ratings for dust and water resistance. Its rugged construction is ideal for high-vibration environments, such as in vehicles or industrial machinery, and it uses SMA connectors for robust connectivity.
Outstanding Technical Specifications
- Image sensor: 1/2.78” progressive scan RGB CMOS
- Lens: Fixed focal, 2.8 mm, F2.2
- Frame rate: Up to 30/25 fps in 5MP and up to 60/50 fps in quad HD
- Wide Dynamic Range (WDR): Forensic WDR up to 120 dB
- Operating temperature: -40 °C to 60 °C
Ideal Use Cases
The AXIS F2107-RE is well-suited for transport and logistics, industrial environments, and any setting requiring durable and reliable monitoring solutions. Its discreet form factor and robust construction make it perfect for both indoor and outdoor use, while its compatibility with AXIS F91 Main Units offers flexible, scalable surveillance options.
