Axis Communications AXIS M7104 4 Channel Video Encoder

Technical Specification

Features:
  • Make: Axis Communications
  • Model code: AXIS M7104
  • Video Inputs: 4
  • Compression Type: H.264/MPEG-4
  • Network Protocols: IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Read more
Additional info:

Adds the benefits of IP surveillance to an analog camera system Supports standard-resolution analog cameras as well as PTZ control over RS-485/422 Features a memory card slot for edge storage and support for intelligent analytics such as motion detection and active tampering alarm Zipstream with support for H.264/H.265 Signed firmware and secure boot

Read more
Make Axis Communications
Manufacturer Axis Communications
Model code AXIS M7104
Video Inputs 4
Compression Type H.264/MPEG-4
Network Protocols IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Interface Analog composite video BNC input RJ45 10BASE-T/100BASE-T/1000 BASE-T PoE
Resolution TVL PAL: 720 x 576; NTSC: 720 x 480
Image per second (IPS) 30 fps
Control PTZ
Physical Specifications Dimensions mm: 187 x 37
Weight g: 650
Electrical Specifications Voltage: PoE, 8 ~ 28 V DC
Power Consumption: 4.7 W
Environmental Specifications Operating Temperature oC: 0 ~ 50 C (32 ~ 122 F)
Operating Humidity %: 10 ~ 85
Protection: IP30
Additional info
  • Adds the benefits of IP surveillance to an analog camera system
  • Supports standard-resolution analog cameras as well as PTZ control over RS-485/422
  • Features a memory card slot for edge storage and support for intelligent analytics such as motion detection and active tampering alarm
  • Zipstream with support for H.264/H.265
  • Signed firmware and secure boot
