LILIN IPR614ES6 Day/night 720P HD IR IP Camera

Technical Specification

Features:

Make: LILIN
Model code: IPR614ES6
Chip Inch Size: 1/4
Color Type: Color / Monochrome
Resolution: 1280 x 768

Additional info:

LILIN IPR614ES6 is a day/night 720P HD IR IP camera featuring H.264 and Motion JPEG multi-profile video streaming, day and night function with mechanical IR cut filter.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	Video Surveillance>IP cameras
Model code	IPR614ES6
Chip Inch Size	1/4
Color Type	Color / Monochrome
Resolution	1280 x 768
Digital (DSP)	Yes
Specialist Type	Infrared
Electrical Specifications	Voltage: 24 V AC Power Consumption: 12W
Motion Activated	Yes
Focal Length mm	6
Picture Elements HxV	1280 x 800
Network Properties	Image Frame Rate: 20 fps Interface: RJ-45, 100Mbps Base-T Network Protocols: IP, TCP, UDP, HTTP, SMTP, ESMTP, NTP, DDNS, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet
Back Light Compensation	Yes
White Balance	Yes
Electronic Shutter Range	1/30(25)S ~ 1/20,000s
Zoom	Yes
Compression Type	H.264/AVC , Motion JPEG
Physical Specifications	Weight g: 1,600 Dimensions mm: 100 x 235
Environmental Specifications	Operating Temperature ^oC: -35 ~ +50 C (-31 ~ +122 F) Protection: IP66
System Requirements	Operating System: Embedded Linux 2.4.19 Web Browser: Windows Internet Explore 6, 7, 8
HD	Yes
Additional info	LILIN IPR614ES6 is a day/night 720P HD IR IP camera featuring H.264 and Motion JPEG multi-profile video streaming, day and night function with mechanical IR cut filter.
