Video Storage Solutions VSS-14 1U 4-Bay Rackmount Video Recording Appliance

Technical Specification

Features:
  • Make: Video Storage Solutions
  • Model code: VSS-14
  • Series: VSS Series
  • Recording system: HDD
  • Storage capacity: 64 TB
Read more
Additional info:

Offers an affordable and reliable 1U rackmount solution for any deployment Up to 64TB of raw video-optimized storage is provided by video grade SATA or dual-port SAS drives The latest Intel® Xeon® E-2136 processor allows for high-powered computing power, and up to 64GB of DDR4 RAM provides the system resources to scale as needed A dedicated solid state drive for applications and the operating system enables fast boot and load times RAID 0, 1, 5, 6 and 10 storage options allow for increased reliability Up to 300 Mbps of Bandwidth Redundant Power iDRAC features include Remote Management, Disaster Recovery, and Critical Resource Monitoring

Read more
Make Video Storage Solutions
Manufacturer Video Storage Solutions
Model code VSS-14
Series VSS Series
Recording system HDD
Storage capacity 64 TB
Secondary storage USB
Removable HDD Yes
Voltage 100 ~ 240 V AC
Power consumption (W) 350 W
Weight (kg) 13.6
Dimensions (mm) 483 x 609 x 43
Operating temperature (°C) 10 ~ 35 C (50 ~ 95 F)
Operating humidity (%) 5 ~ 90
Additional info
  • Offers an affordable and reliable 1U rackmount solution for any deployment
  • Up to 64TB of raw video-optimized storage is provided by video grade SATA or dual-port SAS drives
  • The latest Intel® Xeon® E-2136 processor allows for high-powered computing power, and up to 64GB of DDR4 RAM provides the system resources to scale as needed
  • A dedicated solid state drive for applications and the operating system enables fast boot and load times
  • RAID 0, 1, 5, 6 and 10 storage options allow for increased reliability
  • Up to 300 Mbps of Bandwidth
  • Redundant Power
  • iDRAC features include Remote Management, Disaster Recovery, and Critical Resource Monitoring
Download PDF version Download PDF version
