High-Definition Video Over Analog Infrastructure With New March Networks 8724 V Tribrid NVR

Product Profile

Exhibiting at ISC West 2018: booth number 26047

March Networks’ new 8724 V Tribrid NVR delivers support for high-definition (HD) analog video in addition to IP and standard analog video channels on a single, integrated platform.

The recorder provides organizations with the custom combination of video capture they need right out of the box. It enables them to get sharp HD video using existing analog infrastructure, while avoiding the cost and disruption typically required to replace coaxial cable with Ethernet.

Available in an innovative, space-saving wall mount, and delivering all the reliability and serviceability customers have come to expect from March Networks, the 8724 V Tribrid NVR makes it easy for retailers, financial institutions, school districts and other organizations to transition to an intelligent, HD video solution affordably and at their own pace.

The NVR’s unique design uses analog power and Power over Ethernet (PoE) modules to support a variety of IP and HD analogue video configurations, up to a maximum of 24 channels. For example, an organization could deploy an 8724 V to capture HD video from eight HD analogue and 16 IP cameras at one location, and eight IP and 8 HD analog cameras with another 8724 V at a second site.

All camera licensing is included regardless of the configuration, making the recorder even more cost-effective.

To ensure reliability, the 8724 V incorporates a customized embedded Linux OS that eliminates unnecessary background services and frequent system updates. Other reliability features include diagnostic LEDs, an internal battery backup, and real-time system health monitoring via March Networks Command™ video management software.

The recorder is also simple to maintain, thanks to unique QR codes that work with March Networks’ free GURU Smartphone App to enable instant configuration audits, troubleshooting, warranty checks and other capabilities using a smartphone or tablet.

In addition, the NVR’s modular configuration and convenient form factor also make it an ideal recording engine for the quick service and fast casual markets as part of March Networks’ cloud-based Searchlight for QSR service.

Read more

Technical Specification

Make March Networks
Manufacturer March Networks Corporation
Category Video Surveillance>Network Video Recorders (NVRs)
Model code MN-8724V
Series 8000 Series
Recording Mode Real Time / Timelapse / Event
Video inputs 24
Hardware solution Yes
Inbuilt multiplexer Yes
Recording system HDD
Storage capacity 2TB, 4TB, 6TB, or 8TB
Secondary storage USB
Alarm Handling 2 in, 1 out
Video motion detection Yes
Expandable to multi NVRs Yes
Voltage 110/220 V AC
Power consumption (W) 20 W
Weight (kg) 10.7
Dimensions (mm) 50 x 45 x 19
Operating temperature (°C) 0 ~ 40 C (32 ~ 104 F)
Operating humidity (%) 5 ~ 95
Additional info
  • Built-to-order.
  • High-definition video transmission over coax.
  • Built-in power for cameras.
  • Secure enclosure.
  • All camera licenses included.
  • System-wide health monitoring.
  • Integrate surveillance video with POS, teller and ATM transaction data.
  • QR Code.
