Interlogix TruVision TVN5032 32 IP Channel Network Video Recorder

Product Profile

The new TruVision® NVR 50 (TVN 50) is a high-performance network video recorder designed to support video streams from IP video cameras. With a total of 80 Mbps available, the TVN 50 can support up to 32 cameras at 4CIF in real-time (30fps) and many other configurations. Flexible bandwidth allocation per channel allows users to maximize recording performance. In addition to browser, software and mobile device management tools, the NVR 50’s familiar front panel controls allow for easy operation.

IP camera support includes resolutions ranging from standard VGA to 5.0 megapixel, including Interlogix™ and third-party IP camera manufacturers.* The NVR 50 also supports TruVision encoders for integrating existing analog cameras. Up to eight internal hard disk drives may be configured for a total internal hard drive capacity of 4TB-16TB, making the TVN 50 ideal for extended storage or megapixel camera applications. Recording options include continuous, motion, and alarm or combined scheduled recording modes. Motion recording utilizes an IP camera’s built-in motion detection events, and alarms can be triggered from any of the 16 on-board alarm inputs or from alarm inputs that reside on the IP camera. Software connectivity allows remote access to the recorder’s full capabilities via Web browser or TruVision Navigator.

TruVision Mobile also allows for remote device access. Configuration is quick and easy through startup wizards, IP device auto-discovery tools and ezDDNS service.

The TruVision™ line includes IP components, such as megapixel cameras, recording devices and software, designed to work seamlessly with Interlogix network switches for a ready-made IP solution. The TruVision mobile app allows users to access and monitor their facility's surveillance from anywhere in the world with an iPhone® or iPad®.

The TruVision line from Interlogix brings the benefits of digital security monitoring to commercial applications. Easy to install and operate, TruVision cameras, recorders, monitors and interfaces deliver practical and reliable video surveillance, even in the most challenging environments. For complete security on a moderate budget, the TruVision line is the perfect fit.

*Support from third-party IP cameras may vary.

Read more

Technical Specification

Make TruVision
Manufacturer Interlogix
Model code TVN5032
Series TruVision™ Line
Recording Mode Real Time / Timelapse / Event
Video inputs 32
Inbuilt multiplexer Yes
Multiplexer type Triplex
Type of multiplexer functions Viewing, Playback, Recording
Recording system HDD
Storage capacity 16TB
Storage rate 30 fps
Resolution 4CIF
Signal mode PAL/NTSC
PTZ control Yes
Alarm Handling 16 in, 4 out
Video motion detection Yes
Voltage 100 ~ 240 VAC
Power consumption (W) 45 W
Weight (kg) 8
Dimensions (mm) 445 x 470 x 90
Operating temperature (°C) 10 ~ 55 C (14 ~ 131 F)
Operating humidity (%) 10 ~ 90
Additional info Recording options include continuous, motion, and alarm or combined scheduled recording modes. Motion recording utilizes an IP camera’s built-in motion detection events, and alarms can be triggered from any of the 16 on-board alarm inputs or from alarm inputs that reside on the IP camera.
Download PDF version Download PDF version
