Vicon V2005D-W818MIR 5MP Outdoor IR AI IP Dome Camera
Technical Specification
- Make: Vicon
- Model code: V2005D-W818MIR
- Chip Inch Size: 1/2.8
- Color Type: True Day / Night
- Resolution TVL: 5 MP
5 MP resolution Starlight low-light technology provides clear color images in extreme low-light conditions True WDR (120 dB); built-in varifocal autoiris lens Integrated IR provides uniform illumination in total darkness for high-quality video from 131 ft (40 m) away NDAA compliant; ONVIF S/T/G/M
Read more| Make | Vicon |
|---|---|
| Manufacturer | Vicon Industries |
| Category | Video Surveillance>IP Dome cameras |
| Model code | V2005D-W818MIR |
| Chip Inch Size | 1/2.8 |
| Color Type | True Day / Night |
| Resolution TVL | 5 MP |
| Megapixel | Yes |
| Sensitivity lux | Color: 0.02 lux; BW: 0.01 lux, IR Off; 0 Lux, IR On |
| Indoor/Outdoor | Outdoor |
| Digital (DSP) | Yes |
| Mount Type | Wall, Ceiling, Pole, Corner |
| Electrical Specifications | Voltage: PoE, 12 V DC, 24 V AC |
| Focal length | 8 ~ 18 mm |
| Compression | H.264; H.265; M-JPEG |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | Auto (1/2 ~ 1/10,000 sec), manual |
| Built-in IR LED | Yes |
| Zoom Ratio | x2.25 |
| Network Properties |
Interface: 10/100 Base-T/TX: RJ-45 Network Protocols: ARP, DHCP, DNS, FTP, HTTP, HTTPS, HLS, ICMP, IGMP, IPv4/6, LDAP, NTP, RTSP/RTCP/RTP, RTMP, QoS, SMTP, SNMP v1/2c/3, TCP, TLS/TTLS, UDP, UPnP, 802.1X, UPnP, Bonjour, DDNS, PPPoE; ONVIF S/G/T/M Image Frame Rate: 30 fps / 25 fps Inclusive DVR/ Web Server: Micro SDHC/SDXC |
| Physical Specifications |
Dimensions mm: 135 x 125 Weight g: 1,200 |
| Environmental Specifications |
Operating Temp oC: -40 ~ 60 C (-40 ~ 140 F) Operating Humidity %: up to 90 Protection: IP67, IK10 |
| System Requirements | Web Browser: Chrome®, Safari®, Firefox®, Microsoft Edge® |
Product description
The Vicon Roughneck® AI Dome Camera, model V2005D-W818MIR, is a state-of-the-art surveillance solution designed for demanding environments. This camera offers remarkable 5 MP resolution and is equipped with Starlight low-light technology, allowing for vivid color images even in challenging lighting conditions. Built to withstand extreme weather, it features a vandal-proof housing rated for severe outdoor conditions.
Key Features
- High-Resolution Imaging: Captures detailed footages at 2592x1944 resolution.
- Low-Light Performance: Starlight technology ensures clear visuals in low-light scenarios.
- Integrated IR Illumination: Provides uniform lighting up to 131 ft (40 m), featuring 22 IR LEDs for superior night vision.
- Advanced Object Classification: AI-based analytics distinguish between people, vehicles, and other objects while filtering out irrelevant environmental noise.
- Durable Construction: IP67 and IK10 ratings guarantee resistance to dust, water, and impact.
Technical Specifications
- Focal Length: 8-18 mm motorized zoom with autoiris for precise focus.
- Wide Dynamic Range: 120 dB true WDR for balanced lighting conditions.
- Network Compatibility: Supports various protocols including ONVIF S/G/T/M for seamless integration.
Ideal Use Cases
This camera is perfect for security professionals requiring reliable surveillance in outdoor or high-risk environments. Its ability to perform intelligent object detection and the robust construction makes it ideal for commercial properties, public infrastructure, and any settings exposed to the elements.
