Pelco IMD15127 3x5 MP, WDR, SureVision, 270 degree max field of view, 2.8 mm, Camera Base Module
Technical Specification
- Make: Pelco
- Model code: IMD15127
- Chip Inch Size: 1/2.8
- Resolution: 3x5 MP
- Voltage: 24 V DC, 24 V AC, PoE+
SureVision 2.0 delivers excellent low-light and True Wide Dynamic Range performance Adaptive IR technology extracts security detail in scenes with no light Captures details in very bright and dark areas to maximize image quality Pelco Smart Compression reduces bandwidth and storage needs Rated IK10 for vandal resistance and IP66/67 for water resistance, enabling indoor and outdoor use Is ONVIF Profile S, G and T compliant
Read moreMake | Pelco |
---|---|
Manufacturer | Pelco, Inc |
Category | Video Surveillance>IP cameras |
Model code | IMD15127 |
Chip Inch Size | 1/2.8 |
Resolution | 3x5 MP |
Electrical Specifications | Voltage: 24 V DC, 24 V AC, PoE+ |
Motion Activated | Yes |
Focal Length mm | 2.8 mm |
Mount Type | Surface, Pendant, In-ceiling |
Wide Dynamic Range | Yes |
Back Light Compensation | Yes |
White Balance | Yes |
Electronic Shutter Range | 1/8 to 1/8000 sec |
Compression Type | H.264 Pelco Smart Compression, H.265 Pelco Smart Compression, Motion JPEG |
Network Properties |
Interface: RJ-45, Gigabit Ethernet, 100BASE-TX, 1000BASE-TX Network Protocols: IPv4, IPv6, HTTP, HTTPS, SOAP, DNS, NPT, RTSP, RTCP, RTP, TCP, UDP, IGMPv2, ICMP, DHCP, Zeroconf, ARP, HSTS |
Physical Specifications | Weight g: 1550 |
Environmental Specifications |
Operating Temperature oC: In-ceiling mount: -10 ~ +50 C (14 ~ +122 F) / Surface, Pendant mount: -40 ~ +60 C (-40 ~ +140 F) Operating Humidity %: 0 ~ 95 |
Additional info |
|
Download PDF version Download PDF version |
