Messoa NCC800WL-HP1-EU-MES Color / Monochrome HD Network Cube Camera

Technical Specification

Features:
  • Make: Messoa
  • Model code: NCC800WL-HP1-EU-MES
  • Chip Inch Size: 1/3
  • Color Type: Color / Monochrome
  • Resolution: 2 MP
Read more
Additional info:

Featuring 2-megapixel Full HD resolution at full frame rates, the NCC800WL-HP1-EU-MES is designed for professional indoor surveillance, targeting retail shops, small businesses or offices where image quality is emphasized. The built-in infrared LED gives true, maximized night visibility in complete darkness up to 10 meters. Further enhanced by the proprietary Lumii™ imaging technology, the NCC800WL-HP1-EU-MES provides the unparalleled low light performance like no others. The camera also offers flexible installation, 2-way audio communication, and wireless connectivity to make it a comprehensive and professional business security solution.

Read more
Make Messoa
Manufacturer MESSOA Technologies Inc.
Model code NCC800WL-HP1-EU-MES
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution 2 MP
Digital (DSP) Yes
Specialist Type Network
Sensitivity Lux 0
Electrical Specifications Voltage: 12 V DC
Power Consumption: 7.5 W
Focal Length mm 3.1
Wide Dynamic Range Yes
Picture Elements HxV 1920 x 1080
Network Properties Image Frame Rate: 30 fps
Interface: 10Base-T/100Base-TX, RJ-45
Network Protocols: IPv4, TCP/IP, UDP, HTTP, SMTP, DNS, DHCP, NTP, SSH, FTP, RTP,RTSP, ICMP, UPnP
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter Range 1/10000 ~ 1/3.75 sec
Signal Mode PAL
Y/ C (Video Output) BNC
Compression Type H.264/MPEG4/Motion JPEG
Physical Specifications Weight g: 118
Dimensions mm: 76 x 103 x 42
Environmental Specifications Operating Temperature oC: -10 ~ +50 C (14 ~ 122 F)
Operating Humidity %: 10 ~ 90
System Requirements Web Browser: IE browser 6.0 or above
Additional info Featuring 2-megapixel Full HD resolution at full frame rates, the NCC800WL-HP1-EU-MES is designed for professional indoor surveillance, targeting retail shops, small businesses or offices where image quality is emphasized. The built-in infrared LED gives true, maximized night visibility in complete darkness up to 10 meters. Further enhanced by the proprietary Lumii™ imaging technology, the NCC800WL-HP1-EU-MES provides the unparalleled low light performance like no others. The camera also offers flexible installation, 2-way audio communication, and wireless connectivity to make it a comprehensive and professional business security solution.
Download PDF version
