Lilin Z2R6422AX-P 1080P Day & Night Auto Focus IR Vandal Resistant IP Dome Camera
Technical Specification
- Make: LILIN
- Model code: Z2R6422AX-P
- Chip Inch Size: 1/2.8
- Color Type: Color / Monochrome
- Resolution TVL: 2MP
Full HD 2 megapixel CMOS image sensor 2MP H.265/HEVC and H.264/AVC high-performance video compression Simultaneous streaming of H.265 and H.264 encoded streams Auto focus with zoom / focus motorized lens 3D noise reduction (MCTF) 2D WDR function HDR function up to 100dB Digital PTZ supported IVS supported Tampering / Audio / Alarm / Motion / Network lost detection event function High efficiency IR LED, radiant distance up to 30m Day & Night (IR cut removable) 2-way audio supported Digital I/O : 1 in, 1 out ONVIF Profile S supported IP67 rain and dust resistant Vandal resistant approve
Read moreMake | LILIN |
---|---|
Manufacturer | LILIN |
Category | Video Surveillance>IP Dome cameras |
Model code | Z2R6422AX-P |
Chip Inch Size | 1/2.8 |
Color Type | Color / Monochrome |
Resolution TVL | 2MP |
HD | Yes |
Megapixel | Yes |
Sensitivity lux | 0.007 ~ 0.002 |
Digital (DSP) | Yes |
Electrical Specifications |
Voltage: 12 V DC, PoE Power Consumption: 9 W |
Focal length | 2.8 ~ 8mm |
Compression | H.265, H.264, MJPEG |
Back Light Compensation | Yes |
Auto Gain Control | Yes |
White Balance | Yes |
Electronic Shutter range | 1/30(1/25)s ~ 1/30000s |
S/ N (Signal/ Noise) Ratio dB | 50 |
Network Properties |
Interface: 10/100 Mbps Base-T (Tx), RJ-45 Network Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets Image Frame Rate: 25 ~ 60 fps |
Physical Specifications |
Dimensions mm: 120 x 106 Weight g: 760 |
Environmental Specifications |
Operating Temp oC: -40 ~ 50 C (-40 ~ 122 F) Operating Humidity %: 0 ~ 90 Protection: IP67, IK10 |
System Requirements |
Operating System: Windows 7 or above Web Browser: Microsoft® Internet Explorer® 9 or above |
Additional info |
|
Download PDF version Download PDF version |
