Honeywell Security HNMHE128E64T4R5 128 Channels 16x4 TB RAID5 Network Video Recorder
Technical Specification
- Make: Honeywell Security
- Model code: HNMHE128E64T4R5
- Series: MAXPRO® NVR HE (High Efficiency Edition)
- Recording Mode: Real Time / Event
- Video inputs: 128
Supports simultaneous recording, live monitoring, search and system management for 128 IP cameras including high definition formats 64TB raw storage Provides the processor and RAID enclosure in one chassis RAID 5 support Easy to use desktop clients, web client and mobile apps for remote connectivity and monitoring Intuitive user interface offers feature-rich user experience as intelligence events captured from cameras Ultrakey Keyboard control over ethernet Integrates to full line of Honeywell IP cameras and HVE encoders Support for ONVIF Profile S, G, T; PSIA Native device integrations: 4K resolution, H.265 video compression codec, 3D PTZ control, 360° camera and multi-imager camera support, and intelligence events Multiple NVR deployments for system expansion is easily managed via MAXPRO® VMS enterprise video management system and intelligent command 2U Rack mountable
Read more| Make | Honeywell Security |
|---|---|
| Manufacturer | Honeywell |
| Category | Video Surveillance>Network Video Recorders (NVRs) |
| Model code | HNMHE128E64T4R5 |
| Series | MAXPRO® NVR HE (High Efficiency Edition) |
| Recording Mode | Real Time / Event |
| Video inputs | 128 |
| Software solution | Yes |
| Hardware solution | Yes |
| Inbuilt multiplexer | Yes |
| Type of multiplexer functions | Simultaneous Live, Recording, Playback, Archive |
| Recording system | HDD |
| Storage capacity | 16x4 TB |
| Secondary storage | USB |
| Resolution | 1080p |
| Video motion detection | Yes |
| Client Server NVR Application | Yes |
| Expandable to multi NVRs | Yes |
| Direct client image streaming | Yes |
| Multiple client support | Yes |
| Multiple NVR support | Yes |
| Removable HDD | Yes |
| Operating system | Windows 10 LTSC 2021 |
| Electrical Specifications |
Voltage: 110 / 220 V AC Power consumption (W): 750 W |
| Physical Specifications |
Weight (kg): 38.8 Dimensions (mm): 445 x 86 x 773 |
| Environmental Specifications | Operating temperature (°C): 10 ~ 35 C (50 ~ 95 F) |
Product description
Honeywell Security MAXPRO® NVR HE
The Honeywell MAXPRO® NVR HE, model HNMHE128E64T4R5, is a robust solution for enterprise-level video surveillance needs. Designed to accommodate 128 channels, this Network Video Recorder (NVR) offers a comprehensive suite of features tailored for demanding security environments. Powered by dual Intel Xeon Silver 4310 processors and equipped with 64GB TruDDR4 memory, the NVR ensures top-tier performance and reliability.
Key Features
- Enterprise NVR supporting 128 channels
- 16x4TB HDD configuration with RAID 5 for data integrity and redundancy
- Compatibility with Honeywell's 30/35/60/70 Series IP cameras and a range of third-party devices
- Supports advanced video compression formats: H.264 and H.265
- Audio functionalities with 2-way audio support for supported cameras
- Comprehensive playback and search capabilities and on-screen display options for efficient monitoring
Ideal Use Cases
This NVR is ideal for large enterprises requiring extensive monitoring capabilities across vast spaces. Its robust storage options, scalable from 16TB to 440TB, ensure continuous recording and retrieval over extensive periods, making it perfect for critical infrastructure, large buildings, and multi-site deployments.
The MAXPRO® NVR HE delivers unmatched recording performance and scalability with user-friendly interfaces for effortless configuration and operation. Its robust design ensures reliability under varying conditions, catering to high-security installations.
