Hanwha Techwin XNP-6400RW 2MP 40x IR Wiper PTZ Camera

Technical Specification

Features:
  • Make: Hanwha Techwin
  • Model code: XNP-6400RW
  • Color Type: Color / Monochrome
  • Resolution: 2 MP
  • Specialist Type: PTZ
Read more
Additional info:

2MP resolution @ 60fps IR viewable length : 200m (656ft) 40X optical zoom lens (4.25mm ~170mm) (65.66º ~ 1.88º) -20˚ tilt look-up capability to see above the horizon H.265, H.264, MJPEG triple codec support Multiple streaming, WiseStream II support Day & Night (ICR), extreme WDR DIS with Built-in Gyro sensor Azimuth display (Cardinal & intermediate directions) AI-based Object Auto tracking (Person, Vehicle), target lock tracking, Intelligent video analytics Dual Memory slots (Maximum 512GB x 2) IP66, IK10, NEMA4X, NEMA TS-2 2.2.8 (Vibration) & 2.2.9 (Shock) HPoE (IEEE802.3bt, Class6, Type3, Injector included) UL CAP Cybersecurity certified Optional Network I/O box for alarm & audio I/O(Coming Q1 2021)

Read more
Make Hanwha Techwin
Manufacturer Hanwha Techwin America
Model code XNP-6400RW
Color Type Color / Monochrome
Resolution 2 MP
Specialist Type PTZ
Electrical Specifications Voltage: HPoE
Focal Length mm 4.25 ~ 170
Network Properties Image Frame Rate: 60 fps
Zoom Yes
Compression Type H.265, H.264, MJPEG triple codec
Environmental Specifications Protection: IP66, IK10
Additional info
  • 2MP resolution @ 60fps
  • IR viewable length : 200m (656ft)
  • 40X optical zoom lens (4.25mm ~170mm) (65.66º ~ 1.88º)
  • -20˚ tilt look-up capability to see above the horizon
  • H.265, H.264, MJPEG triple codec support
  • Multiple streaming, WiseStream II support
  • Day & Night (ICR), extreme WDR
  • DIS with Built-in Gyro sensor
  • Azimuth display (Cardinal & intermediate directions)
  • AI-based Object Auto tracking (Person, Vehicle), target lock tracking, Intelligent video analytics
  • Dual Memory slots (Maximum 512GB x 2)
  • IP66, IK10, NEMA4X, NEMA TS-2 2.2.8 (Vibration) & 2.2.9 (Shock)
  • HPoE (IEEE802.3bt, Class6, Type3, Injector included)
  • UL CAP Cybersecurity certified
  • Optional Network I/O box for alarm & audio I/O(Coming Q1 2021)
