Eneo HDB-1080Z03IR 1/3-inch HD-SDI Camera

Features:

Additional info:

Eneo HDB-1080z03IR bullet IP camera with 3x auto focus zoom, integral motion detection and IR LED.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	eneo
Manufacturer	eneo
Model code	HDB-1080Z03IR
Chip Inch Size	1/3
Color Type	True Day / Night
Resolution	1920 x 1080 pixels
Sensitivity Lux	0.1
Electrical Specifications	Voltage: 12 V DC Power Consumption: 10.5 W
Motion Activated	Yes
Focal Length mm	3 ~ 9
Mount Type	wall, ceiling
Wide Dynamic Range	Yes
Auto Gain Control	Yes
White Balance	Yes
S/ N (Signal/ Noise) Ratio dB	-50
Zoom	Yes
Y/ C (Video Output)	HD-SDI (BNC) SMPTE 292M standard, composite control out
Network Properties	Interface: RS-485 Network Protocols: Pelco D, Pelco P, Visca
Physical Specifications	Weight g: 940 Dimensions mm: 76 x 70 x 218
Environmental Specifications	Protection: IP67 Operating Temperature ^oC: -20 ~ +50
HD	Yes
Additional info	Eneo HDB-1080z03IR bullet IP camera with 3x auto focus zoom, integral motion detection and IR LED.
