In part one of this feature, we introduced the shotbolt – a solenoid actuator – as the workhorse at the heart of most straightforward electric locking systems. Shotbolts remain at the core of most sophisticated electric locking solutions as well. But they are supplemented by materials and technologies that provide characteristics suited to specialist security applications. Here we look at some more demanding electric locking applications and contemporary solutions. Preventing forced entry Where the end of the shotbolt is accessible, the electric holding force can be overcome by physical force. That’s why anti-jacking technology is now a frequent feature of contemporary electric solenoid lock actuators. Anti-jacking, dead-locking or ‘bloc’ technology (the latter patented by MSL) is inherent to the way the locking assembly is designed to suit the requirements of the end application. The patented bloc anti-jacking system is highly effective and incorporated into many MSL shotbolts deployed in electric locking applications. The bloc technology uses a ring of steel balls in a shaped internal housing to physically jam the actuated bolt in place. A range of marine locks is widely used on Superyachts for rapid lockdown security from the helm Real life applications for MSL anti-jacking and bloc-equipped shotbolts include installation in the back of supermarket trucks to secure the roller shutter. Once locked from the cab, or remotely using radio technology, these shutters cannot be forced open by anyone with ‘undesirable intentions’ armed with a jemmy. A range of marine locks is widely used on Superyachts for rapid lockdown security from the helm. While anti-jacking features are an option on these shotbolts, consideration was given to the construction materials to provide durability in saltwater environments. Marine locks use corrosion-proof stainless steel, which is also highly polished to be aesthetically pleasing to suit the prestigious nature of the vessel while hiding the innovative technology that prevents the lock being forced open by intruders who may board the craft. Rotary and proportional solenoids sound unlikely but are now common A less obvious example of integrated technology to prevent forced override is a floor lock. This lock assembly is mounted beneath the floor with round-top stainless-steel bolts that project upwards when actuated. They are designed to lock all-glass doors and are arguably the only discreet and attractive way to lock glass doors securely. In a prestigious installation at a historic entranceway in Edinburgh University, the floor locks are remotely controlled from an emergency button behind the reception desk. They act on twin sets of glass doors to quickly allow the doors to close and then lock them closed with another set of subfloor locks. No amount of stamping on or hitting the 15mm protruding bolt pin will cause it to yield, thus preventing intruders from entering. Or leaving! Explosion proofing In many environments, electric locking technology must be ATEX certified to mitigate any risk of explosion. For example, remote electric locking is used widely on oil and gas rigs for stringent access control, general security and for emergency shutter release in the event of fire. It’s also used across many industrial sectors where explosion risks exist, including flour milling, In many environments, electric locking technology must be ATEX certified to mitigate any risk of explosionpowder producers, paint manufacture, etc. This adds a new dimension to the actuator design, demanding not only intrinsically safe electrical circuits and solenoid coils, but the careful selection of metals and materials to eliminate the chance of sparks arising from moving parts. Resilience under pressure The technology boundaries of solenoids are always being pushed. Rotary and proportional solenoids sound unlikely but are now common. More recently, while not directly related to security in the traditional sense, proportional solenoid valves for accurately controlling the flow of hydrogen and gases now exist. Magnet Schultz has an extensive and somewhat innovative new range of hydrogen valves proving popular in the energy and automotive sectors (Fig. 2-6). There’s a different kind of security risk at play here when dealing with hydrogen under pressures of up to 1050 bar. Bio security Less an issue for the complexity of locking technology but more an imperative for the effectiveness of an electric lock is the frequent use of shotbolts in the bio research sector. Remote electric locking is commonplace in many bioreactor applications. Cultures being grown inside bioreactors can be undesirable agents, making 100% dependable locking of bioreactor lids essential to prevent untimely access or the unwanted escape of organisms. Again, that has proven to be topical in the current climate of recurring coronavirus outbreaks around the world. More than meets the eye In part one, I started by headlining that there’s more to electric lock actuation in all manner of security applications than meets the eye and pointed out that while electric locking is among the most ubiquitous examples of everyday security, the complexity often involved and the advanced technologies deployed typically go unnoticed.Integrating the simplest linear actuator into a complex system is rarely simple For end users, that’s a very good thing. But for electro-mechanical engineers designing a system, it can present a challenge. Our goal at Magnet Schultz is to provide a clearer insight into today’s electric locking industry sector and the wide range of locking solutions available – from the straightforward to the specialized and sophisticated. Integrating the simplest linear actuator into a complex system is rarely simple. There’s no substitute for expertise and experience, and that’s what MSL offers as an outsource service to designers. One benefit afforded to those of us in the actuator industry with a very narrow but intense focus is not just understanding the advantages and limitations of solenoid technology, but the visibility of, and participation in, emerging developments in the science of electric locking. Knowing what’s achievable is invaluable in every project development phase.

A defibrillator can save the life of a person suffering from cardiac arrest – but it is most effective when used in the first few minutes of the patient collapsing. Studies have shown that a shock given within the first three minutes provides the best chance of survival and even one minute of further delay can substantially lower the chances of recovering. Public Access Defibrillators (PADs) were created to allow untrained members of the public to deliver life-saving treatment in those precious minutes before an ambulance arrives. There are currently over 10,000 in the UK, located in parks, offices, high streets and sporting venues, and they are especially popular in rural communities, where ambulance response times are longer. Every second counts Over the years there has been a long-running debate as to whether PADs should be kept openly accessible or locked. Leaving them open could lead to theft, vandalism or misuse. Leaving them locked could mean that precious moments are lost waiting for a local guardian to arrive – and could even cost a life. To save as many lives as possible, it’s clear that PADs need to be available 24/7, fully operational and easily accessible to users and local guardians. But there is a solution that can meet all these conditions – a lock that can protect against vandalism while providing convenient instant access when required. Life-saving solutions Over the years there has been a long-running debate as to whether PADs should be kept openly accessible or lockedDigital locks are ideal for securing PADs because they don’t require a key, and anyone can be given access over the phone. In the case of a cardiac arrest, the user calls 999 and the ambulance controller provides them with a simple, easy-to-remember code. The ambulance controller can then advise them, step by step, what to do. Local guardians, who have responsibility for the PAD, can be provided with an override key to enable them to monitor and maintain the defibrillator. The PAD cabinets built by Duchy Defibrillators show exactly how this works in practice. Based in rural Cornwall, Duchy Defibrillators manufactures, supplies and installs monitored PAD cabinets. To provide public access to the defibrillators, it needed a lock that could keep its cabinets secure, make them easily accessible and withstand the stormy Cornish weather. Codelocks recommended a digital electronic lock that could operate on a standalone battery, making it especially suitable for remote areas. As well as offering flexible access, digital locks come with a range of varying options and functions to suit different applications. As Duchy Defibrillator cabinets are installed in a wide variety of locations and sometimes need to withstand outdoor exposure, it opted for a robust electronic digital lock that is both affordable and easy to set up. A digital-access revolution Using smart locks in combination with a dedicated app or portal allows operators to send time-sensitive codes to end-users The example of Duchy Defibrillators shows how digital locks can be used to keep defibrillator cabinets secure while affording instant access to users when they are needed. But the flexibility of digital locks also makes them suitable for securing property and equipment in a wide variety of situations, especially for shared and public facilities. This is why you’ll increasingly see digital locks used to secure restricted areas in hospitals, schools and offices, as well as shared facilities like hotel and gym lockers, public restrooms and more. Digital locks are available for a number of specific applications, including doors, lockers and cabinets. They can range from simple mechanical locks through to more sophisticated electronic locks and state-of-the-art smart locks. Using smart locks in combination with a dedicated app or portal allows operators to send time-sensitive codes to end users – making them very popular for contactless entry and with facilities managers that need to manage access to buildings and campuses. One thing is certain – whatever your access control requirements are, there’s a keyless lock solution to suit. The digital access revolution is here.

The experience of the COVID-19 pandemic has made us all more conscious of who is coming and going from our property. Whether it is a family home, business premises or public building, property owners want full control over access for protection and peace of mind. As a provider of access control technologies, we are seeing a growing demand for automated gates with a variety of access control systems. There are a number of considerations that buyers need to make when investing. And as an installer, there is advice that you can offer to help your clients make the right choice for their property. Here are some of the key considerations you’ll need to make and discuss with your client. Whomever you buy from, you should be offered more than a simple instruction manual. Electronic locks, magnetic locks and code security In the first instance, you’ll need to advise on the type of lock and access control available. Electronic locks release on the operation of the automation system to allow the gates to open. Locks are required for all non-locking (also known as reversible) operators and are recommended for any gate on a multi-user site or any gate over 2.5m. Apply the same logic to an automated gate as you would to a domestic door – for example, you wouldn’t fit your front door with a lock on the same side as the hinges or a drop bolt at the hinge end of a manual gate so why dispense with this logic when the gate is automated? Electronic locks release on the operation of the automation system to allow the gates to open There are a number of locks on the market including magnetic locks, drop locks that “shoot” a bolt into the ground and side latching locks. These are all designed for external use. While the gate itself will provide physical security, the customer will want to feel in control of who enters their property, when and for what purpose. Consider access for mail and deliveries, waste disposal and visitors arriving on foot etc. There is a range of options available. Intercom systems will allow the user to vet visitors, keypad entry can allow remote access for visitors with a specific code, remote controls allow an oncoming driver to open the gates without getting out of the vehicle, and a timer control can be used to open or close the gates at certain times of the day. Vehicle detection loops can be installed discreetly under the tarmac allowing the presence of vehicles to exit the gates and prevent closing while obstructed. Sliding gates versus swinging gates There are a number of locks on the market including magnetic locks, drop locks that “shoot” a bolt into the ground and side latching locks Gates can be automated to either swing or to slide open and in the case of swinging gates, the opener may be concealed underground or gate mounted. The most suitable opener for your installation will depend on the space available and the type of gate selected. Concealed underground automation is ideal for highly ornate gates. However, where gates are fully infilled (typical of many timber designs), gate mounted openers are concealed from the front of the gate by the gate leaf and present a cost-effective option. The choice between slide and swing is largely down to space - swing gates require a clear space for their opening arc while sliding gates require space to one or both sides of the gate. Sliding gates are perhaps the best choice where the drive slopes or when drive space is limited, as they use the least space when opening. Voltage Most swing gate and sliding systems are available in 24v or 230v. The 24v systems still need 230v mains power – there is a transformer built into the 24v control panels. Deciding which voltage to use can include a combination of factors such as the material of the gates, the location of the system and the safety features you want. Concealed underground automation is ideal for highly ornate gates With wrought iron gates, the wind can pass through them whereas with fully boarded wooden gates (popular because they give full privacy) the wind has nowhere to go, so they act like sails. For commercial or industrial applications with larger entrances and a heavy gate, you may need 3 Phase 400v power (sliding gates only). Installing gate motors in confined spaces The environment in which you are fitting may well influence which gate and motor you recommend. Will it be in an exposed area which is subject to the elements? Will it be positioned on a slope? Sliding gates are perhaps the best choice where the drive slopes or when drive space is limited Installers have always faced the challenge of installing gate motors in confined spaces. When fitting a pedestrian gate, there is often limited space in which to work – potentially making an installation time consuming and technically demanding. If this is the case for you, consider a gate operator which is designed specifically for installations with limited space for maneuver. An example of this is the E5 compact gate operator. The operator is not only small but has an optional slide lever attachment designed for installations where there is extremely limited space, meaning that just 8cm of the pillar is needed for installation. What’s more, improved fixing points and a simple ‘hook and fasten’ process means assembly is safe, quick and straight forward. Ultimately, you’ll be looking for a good quality, reliable product with good service. Work with a supplier that offers more than just a manual. If they are happy to offer training, their time and advice when you buy, the chances are you’ll get their support long term.

ASSA ABLOY announces that Medeco Security locks has been recertified for ISO 27001 compliance by Intertek, an independent, multi-national testing and certification firm. ISO 27001 certification affirms that Medeco’s Salem, Va. operation adheres to internationally recognized standards for Information Security Management Systems (ISMS) in the production and sale of the Intelligent Key (electronic locking) systems XT and CLIQ. ISO 27001 certification provides requirements for setting up and maintaining an ISMS in order to keep information assets secure. Medeco’s ISMS is comprehensive, including internal information technology (IT) systems, technical and process controls, policies, procedures, data (Personally Identifiable Information and Intellectual Property) and personnel related to their Intelligent Key product lines. Information security management Continuing to adhere to and maintain ISO 27001 certification is an extremely high priority at Medeco" “Continuing to adhere to and maintain ISO 27001 certification is an extremely high priority at Medeco,” said General Manager Joseph Kingma. “The recertification validates Medeco’s ISMS that was already in place, and has improved upon the framework of policies and procedures that include all legal, physical and technical controls involved in our information security management processes.” ISO 27001 certification assures customers that information being stored on servers or cloud-based systems is handled in a secure manner, minimizing the risk of the exploitation and takeover of data. Information assets can include financial information, intellectual property, employee information and details, and any information supplied by third parties, including vendors and end users. Continuous monitoring and improvement “Medeco’s ISO 27001 certification is of critical importance to our customers,” added Kingma. “They deserve the highest level of integrity from Medeco and, along with delivering the best products and services available in the industry, we must continue to fully protect the information and infrastructure that makes those products secure.”  Medeco’s ISO 27001 certification is valid for three years. Medeco maintains the integrity of its Information Security Management System through continuous monitoring and improvement.

Loughborough University has selected the ASSA CLIQ® Remote system from the ASSA ABLOY Door Hardware Group to help secure its plant control rooms. With more than 18,000 students at Loughborough University for 2018-19, the award-winning ASSA CLIQ® Remote technology has been used across the site for a range of different applications, including teaching laboratories and offices. Its success as a security and access control solution has led to it being extended to cover the university’s plant control rooms too. Providing an easy-to-use electromechanical locking system, the ASSA CLIQ® Remote solution uses high-end micro-electronics and programmable keys and cylinders to offer flexible control over access rights. ASSA CLIQ® Remote solution Loughborough University can program and update each key remotely, removing or granting access privileges for the key holder in real-time. This allows only those with the necessary authority at the university to enter a plant control room. Furthermore, the system removes the security risks associated with lost or stolen keys, eliminating the time and cost spent on replacing a mechanical lock. For staff that have access to these areas and then leave the university, their access rights can be easily be removed by using the system’s simple, web-based interface, ensuring ex-employees and contractors never pose a security risk. ASSA CLIQ® Remote also provides a full audit trail for assured peace of mind around who has accessed the plant control rooms and - because the locks are powered by a battery inside the programmable ASSA CLIQ® Remote key - no extra wiring is required when installing the system. Wireless electronics locks Phil Sheppard, Senior Clerk of Works at Loughborough University, said: “For us, a big advantage to ASSA CLIQ® Remote is that its electronics effectively extend the patent of the key indefinitely. The system cannot be copied, which means ASSA CLIQ® Remote provides a long-lasting access control solution.” “The audit capabilities of the system are also really useful, ensuring we know exactly who accessed a plant control room, and when. The system can be extended really easily as well, which has been another key reason why we continue to use ASSA CLIQ® Remote to meet our access control needs across the university.” “Ultimately, by working with a trusted manufacturer such as ASSA ABLOY, we can be safe in the knowledge that only authorized individuals can access the university’s plant control rooms.” Secure access control solution Sean Falkinder, National Sales Manager for ASSA CLIQ® Remote, adds: “We have provided a range of solutions for Loughborough University over the years, and the use of ASSA CLIQ® Remote for the university’s plant control rooms is just the latest success story. We’re delighted that the technology is able to provide such a safe and secure access control solution for the site.”

Places of leisure, where people spend their downtime, are public by design. Unlike a bank vault or power plant, they actively invite visitors. They can’t just lock be locked down and hope that no one turns up. Equally, to ensure user and property safety, access must not be a free for all. Managing risk, separating authorized from unauthorized people and locations, is part of every site manager’s daily routine. Intelligent locking makes this workload a whole lot easier. Intelligent locking solutions Intelligent keys combine the powerful features of electronic access control with the convenience and familiarity of mechanical keys. In hugely diverse leisure settings across Europe, they already help managers do more with less. The right access solution can help system administrators do it safely without putting a burden on those responsible for everyone’s security. Controlling access to outdoor sites and visitor attractions Robust, battery-powered locking, backed by intuitive admin software can enable access from anywhere Obviously, for many leisure attractions, wired electronic security is not an option. Locations may be remote, far beyond the reach of mains electricity. Assets themselves may be outside. Thankfully, cabling is not essential for effective intelligent access control. Robust, battery-powered locking, backed by intuitive admin software can enable access from anywhere, thereby matching or exceeding the functionality of traditional wired access control. Padlocks built to withstand climate extremes integrate within the system exactly like standard interior locks. Intelligent electronic key systems Intelligent electronic key systems are budget friendly. Making the switch from mechanical security is not an all-or-nothing decision. The best intelligent key systems can be rolled out gradually, as needs evolve and budgets allow. For example, the Llyn Brenig Reservoir and Visitor Center in Wales attract tens of thousands of tourists every year. Both mechanical and electromechanical locking solutions protect a site, which houses critical infrastructure and watersports facilities, with disparate security needs. Here, electromechanical locking brings long-term cost savings to site owners Welsh Water, because locks no longer need to be changed, when keys are lost. Permissions are simply deleted from the system software. Upgrading zoo access control system In 2015, Twycross Zoo launched a £55 million, two-decade development plan. High on the agenda was a new intelligent key solution to replace a mechanical master-key system which was labor-intensive to administer. The new system’s flexibility has put zoo security managers in full control of their site. Only staff with the necessary authority and training can access animal enclosures. It’s simple for system administrators to issue time-defined user keys. These can permit vets or zookeepers access to enclosures for a specific time period outside regular hours, for example, in an emergency. When the period expires, the key no longer works and site integrity is automatically restored. Access control in the museum sector Securing museums, open spaces with priceless contents presents one of security’s biggest challenges When Edvard Munch’s painting ‘The Scream’, was stolen from an Oslo museum in 1994, thieves left a note which read, ‘Thanks for the poor security.’ Securing museums, open spaces with priceless contents presents one of security’s biggest challenges. Around 50,000 artworks are stolen every year, according to some estimates. Adding further complexity, many museums are located within historic properties. The building itself may be integral to the attraction and come with strict heritage protections. Any new locking installation must make minimal mess. For this reason, wireless is increasingly the preferred choice. Wireless access systems Wireless access systems based on robust, key-operated locking, rather than cards and other keyless credentials, combine a familiar technology (the metal key) with the intelligence to keep staff and collections safe. Carrying one programmable key to be able to open doors, cabinets, windows and padlocks makes the security team’s rounds easier. It also minimizes the number of keys in circulation with obvious security benefits. Companion software makes key tracking straightforward, with administrators always knowing who exactly is carrying credentials and they can refine or amend those permissions quickly, and order a full audit trail on demand. And these locks are discreet enough to maintain the property’s appearance. Protecting high-value assets and exhibits London’s Design Museum needed access control designed to protect high-value assets and exhibits. Devices here protect a contemporary site with three galleries, a restaurant/café and an events space, with 100 permanent staff and hundreds (sometimes thousands) of daily visitors. The building has multiple door sizes and must meet British Standards compliance. Electromechanical locks now control access through 56 doors, forming part of a security ecosystem, which incorporates traditional mechanical locks as well. Using intuitive management software, security managers ensure every staff member accesses only the right areas. CLIQ from ASSA ABLOY installed at museum The system the Design Museum chose, CLIQ from ASSA ABLOY, also enables integration with third-party cloud-based solutions Contractors are issued with temporary programmable keys, which saves time formerly wasted escorting them around the building. The system the Design Museum chose, CLIQ from ASSA ABLOY, also enables integration with third-party cloud-based solutions, for control via a single, central management interface. The delicate balance between protecting a precious building and guarding its contents sets a major challenge. Security and access control must be ‘subtle, but ever present,’ according to one former moderator of the Museum Security Network. Invasive installation, showy or inappropriately designed devices and components cannot be considered. CLIQ access control technology This was the checklist facing France’s Musée Maurice Denis, the museum is inside a listed 17th century monument, so they turned to CLIQ access control technology for a solution. Drawing on extensive experience in the heritage sector, ASSA ABLOY delivered class-leading security without disrupting the building aesthetic. Installation was easy and wire-free, because encrypted electronics inside CLIQ locks are powered by the standard batteries inside every programmable key. No further power supply is needed at the door. Robust, hard-wearing cylinders and padlocks installed Around 70 robust, hard-wearing cylinders and padlocks now secure doors and windows inside, and outside the main building with waterproof padlocks protecting CCTV camera that are housed on the exterior. Every employee receives access to relevant areas via a single CLIQ key, which administrators program with only the appropriate permissions. Insurance compliance is another major concern in the heritage sector. Indeed, insurers for 17th century warship, Vasa demand Sweden’s highest level of locking, Class 3. Yet, the Vasamuseet’s access system must also allow 1.2 million annual visitors to move around freely, while keeping exhibits safe. CLIQ Remote electromechanical technology Around 700 interior door cylinders were equipped with CLIQ Remote electromechanical technology To upgrade an existing mechanical system, around 700 interior door cylinders were equipped with CLIQ Remote electromechanical technology. Museum staff used to carry heavy chains with ten or more keys. Now, facility managers can amend the access rights of everyone’s single CLIQ key at any time, even remotely, using the CLIQ Web Manager. It’s easy to issue contractors such as carpenters with access rights scheduled to end automatically as soon as their work is complete. Security for shopping and indoor leisure sites According to one study completed two decades ago, people spend 87% of their time indoors. The number is probably higher now and includes a huge chunk of everyone’s leisure time. Large retail multiplexes like Festival Place in the UK are a popular destination. Here, over 170 shops, a cinema, sports center and restaurants have an ever-changing roster of permanent staff, cleaners and out-of-hours contractors. Every person requires secure entry on demand. The public also needs open access for 18 hours every day. Benefit of CLIQ electromechanical cylinders Yet, a single lost mechanical key could become a security problem for all users and tenants. Installing 100 CLIQ electromechanical cylinders drastically cut the burden of mechanical key management. Now, cleaners and maintenance workers carry an intelligent key, which unlocks specific doors for a pre-defined time period. Using simple online admin software, site managers can immediately de-authorize and reissue a lost key or amend any key’s permissions. Generating a comprehensive audit trail, who accessed which lock and when, takes a couple of mouse clicks. Electronics-inside CLIQ locks CLIQ also cuts Festival Place operational costs. The electronics-inside CLIQ locks are powered by the standard battery inside every key, not mains electricity. Installation was wireless, a huge saving on potentially expensive electrical work. At Festival Place and wherever we gather to enjoy leisure, indoors or outside, CLIQ enables easy access control for all openings with just a simple, single, programmable key.
