Dahua Technology TPC-SD2221-T Thermal Network Hybrid Speed Dome

Technical Specification

Features:
  • Make: Dahua Technology
  • Model code: TPC-SD2221-T
  • Series: Lite series
  • Color Type: Color / Monochrome
  • Sensitivity lux: 0 ~ 0.005
Read more
Additional info:

256x192 VOx uncooled thermal sensor technology Athermalized lens (thermal camera), focus-free 1080P Full-HD image display Support ROI, motion detection, color palettes Support temperature measurement Support smoking detection Smart alarm linkage with white light & loudspeaker Built-in 2/1 alarm in/out Micro SD memory Support Fire detection & alarm

Read more
Make Dahua Technology
Manufacturer Dahua Technology USA Inc.
Model code TPC-SD2221-T
Series Lite series
Color Type Color / Monochrome
Sensitivity lux 0 ~ 0.005
Pan Speed o/ sec 0.1 ~ 200
Indoor/Outdoor Indoor/Outdoor
Digital (DSP) Yes
Tilt Speed o/ sec 0.1 ~ 120
Mount Type Wall, Pole, Corner
Electrical Specifications Voltage: 12 V DC / PoE+
Power Consumption: 24W
Focal length 3.5 mm / 7 mm
Presets 300
Compression H.265; H.264M; H.264H; H.264B; MJEPG
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/1s–1/100000s (auto or manual)
S/ N (Signal/ Noise) Ratio dB >56
Network Properties Network Protocols: HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP
Image Frame Rate: 25 ~ 30 fps
Physical Specifications Dimensions mm: 295 x Φ160
Weight g: ≤3200
Environmental Specifications Operating Temp oC: -30 ~ +60 C (-22 ~ +140 F)
Operating Humidity %: ≤95
Protection: IP66
Additional info
  • 256x192 VOx uncooled thermal sensor technology
  • Athermalized lens (thermal camera), focus-free
  • 1080P Full-HD image display
  • Support ROI, motion detection, color palettes
  • Support temperature measurement
  • Support smoking detection
  • Smart alarm linkage with white light & loudspeaker
  • Built-in 2/1 alarm in/out
  • Micro SD memory
  • Support Fire detection & alarm
