Dahua Technology ASC2208C-S 8-Door 1-Way Access Controller
Technical Specification
- Make: Dahua Technology
- Model code: ASC2208C-S
- Series: ASC2 Series
- Controller Type: Standalone/Networkable
- Max No. of Doors per Controller: 8
An multi-functional access controller with a TCP/IP wired network interface Applicable to industrial parks, office buildings, financial buildings, schools, factories, CBD, residential areas, governments, and more TCP/IP communication Two communication protocols: RS-485 and Wiegand Supports storing 100,000 user and 500,000 card-swiping records Supports multi-door interlock, multi-user unlock, anti-passback, and remote unlock Supports reader tamper alarm, intrusion alarm, unlocking timeout alarm, duress alarm, invalid card exceeding threshold alarm, and incorrect password alarm Supports built-in RTC, manual time fixing, and automatic time fixing Data can be saved permanently in case of power failure; supports online upgrade Power supply through storage battery Supports watchdog mechanism to ensure the operation stability
Read moreMake | Dahua Technology |
---|---|
Manufacturer | Dahua Technology USA Inc. |
Category | Access Control>Access control controllers |
Model code | ASC2208C-S |
Series | ASC2 Series |
Controller Type | Standalone/Networkable |
Max No. of Doors per Controller | 8 |
No of Cardholders | 100,000 |
Networkable | Yes |
Communication Type | TCP/IP, RS485, Wiegand |
Onboard No/Type of Inputs / Outputs | 8 Alarm Inputs, 8 Alarm Outputs |
Universal / Wiegand Reader Interface | Yes |
Electrical Specifications |
Voltage: 100 ~ 240 V AC Power Consumption: < 39.6 W |
Physical Specifications |
Dimensions mm: 337 x 272 x 90 Weight g: 3,500 |
Environmental Specifications |
Operating Temp oC: -30 ~ 60 C (-22 ~ 140 F) Operating Humidity %: 5 ~ 95 Protection: IP20, IK04 |
Additional info |
|
Download PDF version Download PDF version |
