Dahua Technology A42AL23 4MP IR 3.6mm HDCVI Mini Dome Camera

Technical Specification

Features:
  • Make: Dahua Technology
  • Model code: A42AL23
  • Series: PRO Series
  • Chip Inch Size: 1/3
  • Color Type: Color / Monochrome
Read more
Additional info:

True Wide Dynamic Range (120 dB) and 3DNR Maximum 4MP resolution in real-time HD and SD dual-output 3.6 mm Fixed Lens Maximum IR length 30 m (98 ft), Smart IR

Read more
Make Dahua Technology
Manufacturer Dahua Technology USA Inc.
Model code A42AL23
Series PRO Series
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution TVL 4MP
HD Yes
Sensitivity lux 0.01
Digital (DSP) Yes
Indoor/Outdoor Indoor/Outdoor
Mount Type Wall, Pole
Electrical Specifications Voltage: 12 V DC
Power Consumption: 4.4 W
Focal length 3.6mm
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/3 - 1/100,000s
S/ N (Signal/ Noise) Ratio dB >65
Built-in IR LED Yes
Network Properties Image Frame Rate: 25/30 fps
Physical Specifications Dimensions mm: 110 x 81
Weight g: 330
Environmental Specifications Operating Temp oC: -30 ~ +60 C (-22 ~ +140 F)
Operating Humidity %: 0 - 90
Protection: IP67, IK10
Additional info
  • True Wide Dynamic Range (120 dB) and 3DNR
  • Maximum 4MP resolution in real-time
  • HD and SD dual-output
  • 3.6 mm Fixed Lens
  • Maximum IR length 30 m (98 ft), Smart IR
Download PDF version Download PDF version
