Arecont Vision AV05CID-100

Arecont Vision Announces Contera Indoor Dome Megapixel Camera Series

Product Profile

The Contera® Indoor Dome megapixel camera features 1080p and 5-megapixel (MP) resolution for optimum performance. The Contera Indoor Dome combines a day/night mechanical IR cut filter with an integrated motorized remote focus and zoom varifocal lens for excellent, optimal image quality.

Regardless of the time of day, the Contera Indoor Dome is prepared for any lighting condition. For applications with poor lighting conditions, Enhanced WDR™ (wide dynamic range) at 120dB provides the best visual balance to shaded and bright light conditions.

For clear color images in low-light, NightView™ offers strong low-light sensitivity for capturing details in extremely poor-lit scenes. Built-in Smart IR LED illumination automatically adjusts output in response to the distance of an object in view to prevent over-exposure when the object is very close to the camera.

The SD card slot supports up to 256GB of storage capacity for convenient onboard storage. The camera’s power can be supplied via a Power-over-Ethernet (PoE - IEEE 802.3af) compliant network cable connection.

The Contera Indoor Dome is ONVIF (Open Network Video Interface Forum) Profile S and G compliant, providing interoperability between network video products regardless of manufacturer.

Contact manufacturer Datasheet

Make	Arecont Vision
Manufacturer	Arecont Vision
Model code	AV05CID-100
Series	Contera Indoor Dome Series
Chip Inch Size	1/3
Color Type	True Day / Night
Resolution TVL	5MP
Megapixel	Yes
Sensitivity lux	0.01 ~ 0.1
Indoor/Outdoor	Indoor
Digital (DSP)	Yes
Mount Type	Surface
Electrical Specifications	Voltage: PoE Power Consumption: 7.7 W
Focal length	2.7 ~ 13.5 mm
Compression	H.265/H.264 (MPEG-4, Part 10)/Motion JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	0.1ms ~ 500ms
Built-in IR LED	Yes
Network Properties	Interface: 10/100Base-T Ethernet network interface, RJ45 Network Protocols: SNMP, IPv6, IPv4, HTTP, HTTPS, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: 115 x 93 Weight g: 360
Environmental Specifications	Operating Temp ^oC: -10 ~ +50 C (14 ~ 122 F) Operating Humidity %: 10 ~ 90
Additional info	5MP Resolution Remote Focus/Zoom Motorized Lens SNAPstream+™ Capability to Reduce Bandwidth without Impacting Image Quality NightView™ for Strong Low Light Performance True Day/Night Functionality with Mechanical IR Cut Filter Enhanced WDR up to 120dB at Full Resolution: See Clearly in Shaded and Bright Light Conditions Simultaneously CorridorView™ Allows 90° Image Rotation for Better Coverage in Hallways and Corridors Privacy Mask, Motion Detection, Bit Rate Control, Multi-Streaming, Multicasting, Forensic Zooming, and Scaling On-Screen Display (OSD) Defog Technology Triple Encoder: H.265/H.264/MJPEG Network Protocols Include SNMP, IPv6, HTTPS, DHCP, 802.1x, and More All-in-One H.265/H.264 PoE Solution Smart IR Illumination with Variable Illumination Ensures that IR Light is Evenly Disbursed up to 66ft (20m) for Scenes with Low or No Ambient Light SDHC Card Slot for Onboard Storage
Download PDF version

Make

Arecont Vision

Manufacturer

Arecont Vision

Model code

AV05CID-100

Series

Contera Indoor Dome Series

Chip Inch Size

1/3

Color Type

True Day / Night

Resolution TVL

5MP

Megapixel

Yes

Sensitivity lux

0.01 ~ 0.1

Indoor/Outdoor

Indoor

Digital (DSP)

Yes

Mount Type

Surface

Electrical Specifications

Voltage: PoE
Power Consumption: 7.7 W

Focal length

2.7 ~ 13.5 mm

Compression

H.265/H.264 (MPEG-4, Part 10)/Motion JPEG

Back Light Compensation

Yes

Auto Gain Control

Yes

White Balance

Yes

Electronic Shutter range

0.1ms ~ 500ms

Built-in IR LED

Yes

Network Properties

Interface: 10/100Base-T Ethernet network interface, RJ45
Network Protocols: SNMP, IPv6, IPv4, HTTP, HTTPS, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure
Image Frame Rate: 30 fps

Physical Specifications

Dimensions mm: 115 x 93
Weight g: 360

Environmental Specifications

Operating Temp ^oC: -10 ~ +50 C (14 ~ 122 F)
Operating Humidity %: 10 ~ 90

Additional info

5MP Resolution
Remote Focus/Zoom Motorized Lens
SNAPstream+™ Capability to Reduce Bandwidth without Impacting Image Quality
NightView™ for Strong Low Light Performance
True Day/Night Functionality with Mechanical IR Cut Filter
Enhanced WDR up to 120dB at Full Resolution: See Clearly in Shaded and Bright Light Conditions Simultaneously
CorridorView™ Allows 90° Image Rotation for Better Coverage in Hallways and Corridors
Privacy Mask, Motion Detection, Bit Rate Control, Multi-Streaming, Multicasting, Forensic Zooming, and Scaling
On-Screen Display (OSD)
Defog Technology
Triple Encoder: H.265/H.264/MJPEG
Network Protocols Include SNMP, IPv6, HTTPS, DHCP, 802.1x, and More
All-in-One H.265/H.264 PoE Solution
Smart IR Illumination with Variable Illumination Ensures that IR Light is Evenly Disbursed up to 66ft (20m) for Scenes with Low or No Ambient Light
SDHC Card Slot for Onboard Storage
