UltraView UVD-6120VE-2-P 650 TVL True Day/night Rugged Dome Camera

Technical Specification

Features:

Make: UltraView
Model code: UVD-6120VE-2-P
Chip Inch Size: 1/3
Color Type: True Day / Night
Resolution TVL: 650

Additional info:

The Ultraview UVD-6120VE-2-P true day/night rugged dome camera features a removable IR-cut filter, varifocal lens and a weatherproof, vandal-resistant rugged enclosure. The Digital Image Stabilizer (DIS) function suppresses the image shaking that can occur when cameras are mounted outdoors in higher locations,

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	UltraView
Manufacturer	Interlogix
Category	Video Surveillance>Dome cameras
Model code	UVD-6120VE-2-P
Chip Inch Size	1/3
Color Type	True Day / Night
Resolution TVL	650
Dome Type	Static
Sensitivity lux	0.08
Indoor/Outdoor	Indoor/Outdoor
Digital (DSP)	Yes
Mount Type	Wall, Corner
Electrical Specifications	Voltage: 24 V AC Power Consumption: 3 W
Focal length	2.8 ~ 10 mm
White Balance	Yes
Electronic Shutter range	1/50 s ~ 1/10,000 s
S/ N (Signal/ Noise) Ratio dB	52
Synchronisation	Internal
Signal Mode	PAL
Video Output	1 Vp-p composite output (75 Ohm/BNC)
Physical Specifications	Weight g: 1,130
Environmental Specifications	Operating Temp ^oC: -30 ~ +50 C (-22 ~ +122 F) Protection: IP66
Additional info	The Ultraview UVD-6120VE-2-P true day/night rugged dome camera features a removable IR-cut filter, varifocal lens and a weatherproof, vandal-resistant rugged enclosure. The Digital Image Stabilizer (DIS) function suppresses the image shaking that can occur when cameras are mounted outdoors in higher locations,
