Teleste CFO460 Four Channel Video Link
Technical Specification
- Make: Teleste
- Model code: CFO460
- Video Inputs: 4
- Data Input: Yes
- Audio Input: Yes
Teleste CFO460 four channel video link provides a low cost video transmission by utilising the standard swappable SFP optics for a proprietary point-to-point communication. In addition to enchanged 8 bit video, multiple RS-data channels and dual audio capacity, the CFO460 modems have also a built-in Fast Ethernet Bridge to carry IP services as well. It utilizes uncompressed digital technology to provide a high performance video transmission. All common composite video formats are supported.
Read more| Make | Teleste |
|---|---|
| Manufacturer | Teleste Corporation |
| Category | Video Surveillance>Video servers (IP transmission) |
| Model code | CFO460 |
| Video Inputs | 4 |
| Data Input | Yes |
| Audio Input | Yes |
| Interface | 10/100Base-TX |
| Bandwidth MHz | 5.8 |
| Physical Specifications | Weight g: 500 |
| Electrical Specifications |
Power Consumption: 450 mA Voltage: 14 V DC |
| Environmental Specifications |
Operating Temperature oC: -34 ~ +74 C (-29 ~ +165 F) Operating Humidity %: 0 ~ 90 |
| Video Inputs Overview | BNC female |
| Additional info | Teleste CFO460 four channel video link provides a low cost video transmission by utilising the standard swappable SFP optics for a proprietary point-to-point communication. In addition to enchanged 8 bit video, multiple RS-data channels and dual audio capacity, the CFO460 modems have also a built-in Fast Ethernet Bridge to carry IP services as well. It utilizes uncompressed digital technology to provide a high performance video transmission. All common composite video formats are supported. |
