System OverviewThis PIR model is an indoor/outdoor dual detection camera which uses both video and infrared sensor to achieve accurate motion detection functionality. It also supports active deterrence feature which warns off intruders with white light and siren even before users are aware of the incident. This camera is an ideal choice for applications which require intrusion protect and video verification , such as courtyards, offices, warehouses, stores, etc. Functions 4 Signals over 1 Coaxial CableHDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology supports PoC for construction flexibility.* Audio input is available for some models of HDCVI cameras. Long Distance TransmissionHDCVI technology guarantees real-time transmission at long distance without any loss. It supports up to 700m transmission for 5MP HD video via coaxial cable, and up to 300m via UTP cable.**Actual results verified by real-scene testing in Dahua's test laboratory. SimplicityHDCVI technology inherits the born feature of simplicity from traditional analog surveillance system, making itself a best choice for investment protection. HDCVI system can seamlessly upgrade the traditional ana-log system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network. Dual DetectionThe detection accuracy is well guaranteed with both motion detection and PIR detection, which can eliminate the number of false alarms you receive. With the advantage of dual detection technology, your HDD will now last longer and not be recorded with false alarms. Gone are the days of alarms caused by heavy wind or rain. Instead, only true threats will instantly trigger an alarm and allow you to protect your loved ones. Active DeterrenceActive deterrence is to warn off intruders actively with white light and siren even before users are aware of the incidence. Once an intursion is detected, the white light will turn on and the siren will buzzer to alert the intruder. The white light can be set to Normally on or Flash, the content of siren is configurable. StarlightWith the adoption of large sized high performance sensor, the camera is able to provide incomparable performance even under extreme lowlight environment. The starlight feature allows more details to be captured and accurate color to be recognized at night or in scenes with limited illumination. Smart IRThe camera is designed with array LED IR illumination for best lowlight performance. Smart IR is a technology to ensure brightness uniformity in B/W image under low illumination. Dahua’s unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensate for the distance of an object, and prevents IR LEDs from overexposing images as the object come closer to the camera. ProtectionThe camera's outstanding reliability is unsurpassed due to its rugged design.The camera is protected against water and dust with IP67, making it suitable for indoor or outdoor environments.With PIR working temperature range of -20 °C to +60 °C (-4 °F to +140 °F), the MotionEye is designed for extreme temperature environments. Supporting ±30% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning.
In Mirasys VMS Version 8 particular attention has been paid to security and privacy. Also, pre-existing familiar product features such as audit trail and versatile material management and search functionality brings significant benefits, for example, for the new EU General Data Protection Regulation (GDPR) requirements. Mirasys V8.4 is also a foundation for totally new opportunities related to this; what comes to system management and usage reporting, for example. Functional Effectiveness Mirasys VMS is quick and easy to install, and especially effective in networked, IP-based CCTV systems and their operational and management needs, such as centralized management and upgrading/updating of servers, drivers and client applications without requiring on-site travel to remote locations. User profiles are easy to create and change. Servers can be pre-installed and pre-configured before delivering to the deployment location. The Mirasys VMS V8 modern Spotter for Windows user interface can be adapted to individual and specific needs and preferences and provides more visual space for videos without sacrificing any functionality. The new HTML5 (Hypertext Markup Language, Version 5) based user interface in V8.4 offers easy access to the Mirasys system from anywhere; PCs, tablets or smartphones. Integration With Other Systems Video management systems are also more and more frequently integrated with other systems such as building management or access control. Video feeds will in the future also often be a replacement for on-site visits or tours by personnel. This reduces operational costs for security and building maintenance. User Interfaces Video surveillance camera features are consistently improving. Image quality can be exceptionally good compared to what it used to be only a few years ago. The newest cameras also require much less network bandwidth due to more effective encoding formats, such as H.265/HEVC (from 40% up to 60% of bandwidth and storage space savings, depending on the footage and device without any loss of quality, or increased quality at the same level with the H.264/AVC encoding) that many IP camera manufacturers have started to support. Individual servers can handle more simultaneously connected cameras than before, and the entire system no longer has an actual upper limit. Mirasys VMS V8 is the answer to the scalability and performance needs of new camera technologies from any manufacturer. Thus, the video management system can be designed freely using the best equipment for the customer-specific requirements, and can also support all future needs. User-Specific Requirements As video management evolves, traditional command and control (monitoring) services also change. In addition to security monitoring, this will also involve monitoring other systems (building management, access control, fire alarms, or even manufacturing, logistics and operational systems or processes). More and more often these are done by a service provider, and not the organization whose premises, systems or processes are monitored and/or managed. Further, systems today have more and more different types of users; and variation in user skills or access rights can be significant. This leads to individual, user-specific requirements for system access and use, while simultaneously requiring that the users must be able to access the system from different locations and using different devices. Versatile Possibilities And Efficiency Of Management For systems integrations and management, Mirasys VMS Version 8.4 brings new and more versatile possibilities with its new HTTP based Application Programming Interface (API). A particularly significant benefit is that the HTTP API allows also for automation of the system configuration and management. The new HTTP API provides modern REST-compliant (Representational State Transfer, or ”RESTful”) web services which allow requesting systems to access and manipulate textual representations of web resources using a uniform and predefined set of stateless operations from any platform (almost any operating system and practically any programming language). Version 8.4 also brings a new software licensing model that brings remarkable simplification, effectiveness and cost savings, because from V8.4 onwards every server no longer requires its own server-specific software license, but all the software and licence features and limits (such as number of cameras, number of servers, number of simultaneously logged in users or any other functions) can, in any size system, be managed through a single system-wide software licence controlled via the system’s Management servers. The new V8.4 licences are also no longer dependent on the server’s MAC (Media Access Control) address, but uses a multi-factor “License Protection Key” that remains valid even if the hardware system has to be changed (e.g., new or replacement NIC, Network Interface Card, or new or replacement graphics controller, etc.).
The Contera NVR Appliance from Arecont Vision Costar is designed to offer powerful IP recording in an affordable, compact chassis. The Contera NVR Appliance is equipped with an on-board 8 or 16 channel PoE switch, that can be upgraded to 24 channels, allowing for Plug and Play connection with ConteraWS® or ONVIF cameras. With full integration to ConteraWS® Web Services, the Contera NVR Appliance offers centralized user management, single sign-on convenience, mobile apps and a web client that allows for easy remote connection to your recorders. Network setup is fast and easy using ConteraWS® Web Services, and eliminates the need for port forwarding or DDNS. The Contera NVR Appliance runs on a secure Linux OS and comes preloaded with ConteraVMS® Server software as a turnkey solution.
The Evolution Stainless Steel cameras, part of Oncam’s Specialist Camera Range, are unique to the 360-degree video surveillance market as they are the only ones certified for tough environments, indoor and outdoor. The 05MP and 12MP versions have been specifically designed to meet the needs of customers operating in demanding environments such as Food Processing, Industrial, Maritime and Ports and Safe City applications. The cameras’ resilient Stainless Steel 316 housing is manufactured for enhanced corrosion resistance. The IP66, IP67, IP68, IP69K, and NEMA 4X and 6P ratings make the enclosure fit for harsh environments, while its IK10+ rating makes it resistant to impacts of 40 joules. The NSF certification and HCV EU mark make the camera range unique, guaranteeing compliance with standards for commercial food equipment in both North America as well as Europe. The only 360-degree fisheye camera in a stainless steel housing, Oncam’s new and improved camera range is available for surface and pendant mount installations. A matching stainless steel arm allows for wall, corner and pole mounting. Evolution 05 Stainless Steel: EVO-05-SS2 Evolution 12 Stainless Steel: EVO-12-SS2
VIVOTEK’s FE9391-EV is the next generation of market-leading 12-Megapixel 360° panomorph network camera, featuring a detailed 12-Megapixel CMOS sensor which guarantees superb image quality. Utilizing the latest in panomorph lens technology for 180° panoramic view (wall mount) or 360° surround view (ceiling/wall/floor mount) with zero blind spots, the camera is able to provide comprehensive coverage of open areas such as airports, shopping malls, parking lots, retail stores, offices and more. Removable IR-Cut Filter The FE9391-EV (IP66, IK10 rated) is the successor to FE8391-V in the VIVOTEK 360° surround view family. The new model is equipped with a removable IR-cut filter and WDR Enhancement technology, allowing the camera to maintain optimal image quality around the clock for unparalleled visibility under high-contrast lighting environments. 3D Noise Reduction technology enables the camera to capture clear, polished video under low-light conditions. The FE9391-EV's use of the latest in panomorph lens technology has led to much improved image quality with a huge drop in edge distortion. Latest In IR Illumination The FE9391-EV is also updated with the latest in IR illumination, VIVOTEK's Smart IR II technology with Adaptive IR. Adaptive IR enables the FE9391-EV's IR illuminators to adjust to the scene together or individually to provide the best possible IR image, reducing glaring hotspots and/or underexposed dark spots. Advanced Video Content Analysis The FE9391-EV is also be the first to include a new wave of advanced Video Content Analysis (VCA). Available in 4Q 2017, this includes better object detection in order to reduce false alarms. Through advanced Video Content Analysis functions including crowd detection features the FE9391-EV is the next steps in elevating surveillance cameras from image capturing devices to advanced notification instruments, allowing users to see more in smarter ways.
Associate recorded video footage with access control events in a single system Always get video verification of cardholder with live views of doors Access from anywhere, at anytime and on any device Compatible with leading browsers (Internet Explorer, Google Chrome, Firefox) Smart Phone App for iOS and Android
The Avigilon H4 Multisensor camera combines self-learning video analytics with exceptional coverage, featuring 3 or 4 individually-configurable sensors that can be positioned to monitor virtually any area. With 9-32 MP total resolution, it delivers broad coverage and high image detail, and uses H.265 compression technology to reduce bandwidth and storage requirements while maintaining clear images. Each camera sensor incorporates Avigilon self-learning video analytics and works with Avigilon Appearance Search™ technology, our award-winning AI video search engine.
Hikvision, the world’s leading supplier of innovative security products and solutions, has introduced new AcuSense network camera series to its EasyIP 4.0 security solutions. Featuring a strobe light and an audio alarm, the new cameras can immediately deter intruders from entering a prohibited site, further enhancing the safety of premises and property. At The Core: Faster, More Accurate Intrusion Detection Importantly, Hikvision AcuSense network cameras build on the same cutting-edge intrusion detection functionality found within the existing Hikvision EasyIP 4.0 security solutions. When a potential threat is detected by the camera, it uses its intelligent false alarm reduction technology to disregard irrelevant movements, such as rain, leaves and animals. Instead, the camera focuses on human or vehicle movement, dramatically reducing the number of false alarms for faster, more accurate intrusion detection. An Enhanced Deterrent: Strobe Lighting And AlarmOnce a potential intruder has been accurately detected, the AcuSense network camera triggers the built-in strobe light and audio alarm. This is designed to warn the intruder off before they attempt to breach the perimeter. The volume of the audio alarm and the brightness of the strobe light can be adjusted to suit the environment. Reliable Operation, Day Or NightThe AcuSense network camera range can deliver this powerful intrusion detection and prevention at all times of day or night. Powered by Hikvision DarkFighter technology, all cameras in the range deliver superior surveillance images, even in ultra-low light. Four Products To Suit Different ApplicationsThe new AcuSense network cameras are available in bullet and turret styles, and in 2MP or 4MP resolution, making a total of four different camera options available. Better Service, Greater Peace Of MindFrank Zhang, General Manager of International Product Marketing Department at Hikvision says, “AcuSense technology is already cutting-edge. By adding the strobe light and the alarm, we can now give our customers the chance to prevent incidents from happening in the first place, for even better security. We’re delighted to be able to help our customers protect their property in ever more valuable ways.” Product Model DetailsThere are four models available:• DS-2CD2346G1-I/SL: 4 MP IR Fixed Turret Network Camera• DS-2CD2326G1-I/SL: 2 MP IR Fixed Turret Network Camera• DS-2CD2T46G1-4I/SL: 4 MP IR Fixed Bullet Network Camera• DS-2CD2T26G1-4I/SL: 2 MP IR Fixed Bullet Network Camera
March Networks’ new ME3 Pendant IR PTZ camera delivers uncompromising security for large indoor and outdoor spaces, as well as essential features to ensure high reliability, clear image capture and storage efficiency. Ideal for large-footprint environments such as parking lots, big box stores and transit stations, the camera incorporates electronic image stabilisation and HDR, so recorded video is always crisp. Universal Power over Ethernet (UPoE) ensures redundancy and zero downtime by switching to PoE when a camera loses power. And built-in PTZ auto-tracking uses motion detection to automatically track a person or object, keeping the image centered and in focus. Software updates are quick and easy to apply using the mass management feature available in Command Enterprise software, while PTZ-optimized motion histograms speed search capabilities. The 3MP PTZ includes a 40x zoom lens to capture objects 25% further away than industry-standard PTZs, and IR LEDs for uniform illumination in total darkness at a distance of more than 650 feet/200 metres. It also incorporates a Low Bit Rate compression mode to improve bandwidth and storage efficiency by as much as 50% when the camera is in its home position. The ME3 Pendant IR PTZ is protected by a weather-proof enclosure, and generates an alert in the event someone attempts to obstruct or move the camera. It comes with a variety of mounting options, including a 1.5” NPT wall mount and short pendant mount, both with back boxes.
System Overview MXVR1004 is the new generation of mobile video recorder, it uses H.265 technology and the advantages are lowering the transmission bandwidth and saing the storage. It can support 1080P high-definition real-time recording, real-time vehicle location tracking and monitoring and the face detection. All the information such as GPS and video can be uploaded via wireless network: 3G/4G/WIFI. It has already passed EN50155/ISO16750 in order to meet the requirements of mobile use.This device can be used in kinds ofsolutions for different applications. Functions Anti-vibration- Using shock-absorbing material and structure, the new designed hard disk box can cope with varying degrees of vibration, keeping the system work normally all the time. Wide range of power supply- As the voltage output of vehicle battery changes during driving, the wide range of power supply can protect the device. 3G/4G/WIFI- Embedded with 3G/4G/WIFI module, the device can register into a public network to connect with VMS, and can send all theinformation(video/audio/alarm/gps) through wireless network. GPS- Embedded GPS module can receive location information and upload to VMS. Even when the device is offline, it can upload theinformation after it's online again and the vehicle can be tracked on the electric map of VMS. Multiple ports- With kinds of ports, like RS232, RS485, I/O, the video recorder can connect with various of accessories, such as card reader, fuelsensor, panic button and so on.system), so that the video, audio, alarm and location information can be uploaded to VMS.
Since 2011, the patented Dallmeier Panomera® multifocal sensor technology has provided comprehensive video protection for vast areas in many football stadiums, perimeters, airports and city areas all over the world. The new Panomera® series, the “Ultraline“, has exceptionally high effective resolution for these situations. Dallmeier presents the first model of the new series, the Panomera® S8 Ultraline, which delivers up to 190 megapixel at 30 fps. The Panomera® concept has revolutionized video technology: with up to eight sensors in a single camera, it is possible to capture enormous distances in unprecedented resolution quality. With fewer cameras and considerably less expense for both infrastructure and management, the total cost of ownership of video solutions are reduced significantly. At the same time, customer specifications regarding pixel density and coverage can be satisfied very precisely. Up To 26,000 sqm. Coverage With One Camera The first model of the new Ultraline series, the Ultraline S8, has an excellent dynamic range of 130 dB UWDR (effective) for an extreme Panomera® effect. This enables a resolution of 125 px/m up to a distance of 160, 104 or 82 m, enabling individuals to be recognized over the entire distance. Identification of persons (250 px/m) is supported up to a distance of 46 m depending on the model, observation (62 px/m) is possible even up to a distance of 322 m. This corresponds to a huge image space of more than 26,000 sqm. with continuous depth of field. Permanent Capture The multifocal sensor system captures and stores all regions of the image space in the highest detail resolution. At the same time, it is not important whether the operators are concentrating on a specific region in live mode (multiple detail zoom) or if regions of interest are displayed in detail based on video content analysis (multiple auto-tracking). The Panomera® recordings always include the entire area of interest and allow every operation to be analyzed. “Made in Germany” And GDPR-Ready Like all Dallmeier cameras the new Panomera® model is manufactured entirely in Germany, at the Dallmeier factory in Regensburg. This in itself is a major factor in the manufacturer’s data protection and data security strategy, since it is then impossible for unauthorized persons to gain access through “backdoors”, for example. In all, 14 functions such as the setup of private zones, People Masking or the very latest encryption-authentication technology in the processing chain of Dallmeier solutions ensure that the strict requirements of the GDPR relating to data protection and data security are met.
The Evolution ExD Cameras, part of Oncam’s Specialist Camera Range, are unique to the 360-degree video surveillance market. Both ATEX, IEC and IECEx certified, the 5MP and 12MP versions have been specifically designed to meet the needs of customers operating in hazardous environmental conditions and potentially explosive atmospheres. The cameras’ housings are manufactured in Stainless Steel 316L, for maximum robustness. The IP66, IP67 and IP68 ratings make the enclosure resistant to harsh environmental conditions. Fit for use in markets such as Offshore and Onshore Environments, Industrial and Chemical Plants, Ports and Marine Applications and Food Processing Areas, the world’s first and only 360-degree ExD camera range is available in four mounting options: Surface Mount, Wall Mount, Pole Mount and Ceiling Mount. With no moving parts, the cameras can be PoE, 12 VDC or mains powered, dependent on whether they will be used indoor, outdoor or in extreme outdoor conditions. A heater is also available in the outdoor models. For enhanced connectivity in extreme outdoor applications, single or multi-mode fibre versions are offered. Indoor: EVO-05-EIP / EVO-12-EIP (PoE) Outdoor: EVO-05-EOA / EVO-12-EOA (115V) EVO-05-EOE / EVO-12-EOE (230V) Extreme Outdoor: EVO-05-ESA / EVO-12-ESA (115V, Single Fibre Optic Mode) EVO-05-ESE / EVO-12-ESE 230V, Single Fibre Optic Mode) EVO-05-EMA / EVO-12-EMA (115V, Multi Fibre Optic Mode) EVO-05-EME / EVO-12-EME (230V, Multi Fibre Optic Mode)
Ultra-narrow 1.7mm bezel-to bezel design(1.15mm bezel on the left and top sides and 0.55mm bezel on the right and bottom sides) High contrast and high brightness greatly enhance the video layering, and present the details of the video High fidelity digital processing for a brilliant and vivid video Built-in 3D COMB filter and 3D noise reduction Wide array of connectivity options HDMI, DVI, VGA, BNC, RS232, USB, Audio Infrared, RS232 double mode, supporting remote PC control Brightness smart detection, power-saving Professional thermal design to extend equipment lifespan Built-in power, low energy consumption, ultra-quiet Fast stack installation, professional project design, supporting arc-shaped mounting Widely used in surveillance center, dispatching platform, safe city, commercial display, etc.
Multiplexer products updated recently
Critical infrastructure facilities that must secure large areas with extended outer boundary and numerous entry points, present a particularly difficult challenge when it comes to perimeter protection. As such, true end-to-end perimeter protection calls for the utilization of a sophisticated, multi-layered solution that is capable of defending against anticipated threats. Integrated systems that incorporate thermal imaging, visible cameras, radar and strong command and control software are crucial for covering the various potential areas of attacks. Let’s look at these technologies and the five key functions they enable to achieve an end-to-end solution that provides intrusion detection, assessment and defense for the perimeter. 1. Threat Recognition The first step in effectively defending against a threat is recognizing that it’s there. By combining state-of-the-art intrusion detection technologies, facilities can arm themselves with a head start against possible intruders. An exceptionally important aspect of effective perimeter protection is the ability to conduct 24-hour surveillance, regardless of weather conditions, environmental settings, or time of day. Visible cameras do not perform as well in low light scenarios and inclement weather conditions. However, thermal imaging cameras can provide constant protection against potential intruders, regardless of visual limitations, light source or many environmental factors. In fact, facilities such as power stations located near bodies of water can use thermal cameras to create what is known as a “thermal virtual fence” in areas where they are unable to utilize the protection of a physical fence or wall. Deterring suspicious activity can be achieved through real-time two-way audio, a simple but powerful tool Critical infrastructure applications require not only continuous video surveillance and monitoring, but also a solution that yields highly reliable intrusion detection, with fewer false alarms. This need makes advanced video analytics a must for any adequate surveillance system. Features like dynamic event detection and simplified data presentation are game changing in supporting accurate intrusion analysis and facilitating a proactive response. Advanced analytics will provide multiple automated alarm notification options, including email, edge image storage, digital outputs or video management software (VMS) alarms. Incorporating high quality, unique and adaptive analytics can virtually eliminate false alarms, allowing security personnel to respond more efficiently and effectively, while also lowering overall cost for the end user. While surveillance technologies such as radar, thermal imaging and visible cameras, or video analytics work well on their own, utilizing all of these options together provides an advanced perimeter detection system. For example, ground surveillance radar can detect possible threats beyond the fence line as they approach and send a signal to pan-tilt-zoom (PTZ) cameras, triggering them to slew to a specific location. From there, embedded analytics and visible cameras can further identify objects, notify authorized staff, and collect additional evidence through facial recognition or high-quality photos. 2. Automatic Response Systems Once an intrusion attempt is discovered, it is important to act fast. Organizing a response system that can initiate actions based on GPS location data, such as the slewing of PTZ cameras, automated intruder tracking or activated lighting sensors, greatly increases staff’s situational awareness while easing their workload. For instance, thermal imagers deployed in conjunction with video analytics can be used to generate an initial alarm event, which can then trigger a sequence of other security equipment and notifications for personnel to eventually respond to. Having all of this in place essentially lays the entire situation out in a way that allows responders to accurately understand and evaluate a scene. Power stations located near bodies of water can use thermal cameras to create a “thermal virtual fence” in areas where they are unable to utilize the protection of a physical fence or wall 3. Deterring Suspicious Activity After the designated auto-response mechanisms have activated and done their job, it is time for responders to acknowledge and assess the situation. From here, authorized personnel can take the next appropriate step toward defending against and delaying the threat. Deterring suspicious activity can be achieved through real-time two-way audio, a simple but powerful tool. Often, control room operators can diffuse a situation by speaking over an intercom, telling the trespasser that they are being watched and that the authorities have been notified. This tactic, known as ‘talk down’, also allows officers to view the intruder’s reaction to their commands and evaluate what they feel the best next step is. If individuals do not respond in a desired manner, it may be time to take more serious action and dispatch a patrolman to the area. 4. Delay, Defend, Dispatch And Handle The possible danger has been identified, recognized and evaluated. Now it is time to effectively defend against current attacks and slow down both cyber and physical perpetrators’ prospective efforts. Through the use of a well-designed, open platform VMS, security monitors can manage edge devices and other complementary intrusion detection and response technologies, including acoustic sensors, video analytics, access control and radio dispatch. A robust VMS also enables operators to control functions such as video replay, geographical information systems tracking, email alerts and hand-off to law enforcement. With the right combination of technologies, facilities can take monitoring and evidence collection to the next level The primary purpose of the delay facet of the overall perimeter protection strategy is to stall an attempted intrusion long enough for responders to act. Access control systems play a key role in realizing this objective. When a security officer sees a non-compliant, suspicious individual on the camera feed, the officer can lock all possible exits to trap them in one area all through the VMS. 5. Intelligence: Collect Evidence And Debrief More data and intelligence collected from an event equals more crucial evidence for crime resolution and valuable insight for protecting against future incidents. With the right combination of technologies, facilities can take monitoring and evidence collection to the next level. One innovative resource that has become available is a live streaming application that can be uploaded to smart phones and used for off-site surveillance. This app gives personnel the power to follow intruders with live video anywhere and allows operators to monitor alarm video in real-time. Geographic Information System (GIS) maps are computer systems utilized for capturing, storing, reviewing, and displaying location related data. Capable of displaying various types of data on one map, this system enables users to see, analyze, easily and efficiently. Multi-sensor cameras, possessing both visible and thermal capabilities, provide high-contrast imaging for superb analytic detection (in any light) and High Definition video for evidence such as facial ID or license plate capture. Integrating these two, usually separated, camera types into one helps to fill any gaps that either may normally have. Still, in order to capture and store all of this valuable information and more, a robust, VMS is required. Recorded video, still images and audio clips serve as valuable evidence in the event that a trial must take place to press charges. Control room operators can use data collection tools within their VMS to safely transfer video evidence from the field to the courtroom with just a few clicks of their mouse. More advanced video management systems can go a step further and package this data with other pertinent evidence to create a comprehensive report to help ensure conviction.
Technology is changing the look and function of today’s security control rooms. Old-school CRT (cathode-ray tube) monitors are giving way to the thinner, flat screen monitors in the control room environment, but the transition is gradual. Randy Smith of Winsted still sees many control rooms that need to make the conversion, which is a boon to his company’s business. Furniture today is designed differently to accommodate the thinner monitors, often with larger screens. Need For Integrated Rack Systems With the increase of IP-based systems comes the need for integrated rack systems that include advanced functionality such as cable management, adds Jim Coleman, National Sales Manager, AFC Industries. Server rooms are environmentally controlled by cooling systems and power systems monitored on the IP network. Low-profile flat screens allow centers to utilize space vertically, thus creating a smaller footprint for the consoles. Additionally, with IP-based systems, workstations will have a smaller footprint because there is less cumbersome equipment. In most cases the servers are stored in a secured, climate controlled environment to eliminate overheating of the servers and maintain their security, says Coleman. This environment also helps with cable and power management. AFC builds technical furniture racks that adhere to the precise needs of computer network server room operators. The company designs and fabricates LAN workbenches with versatile functionalities, and server room workstation racks that are scalable. There is a complete line of IT workbenches, IT computer racks and computer server rack mounts with flexible mounting options. In most cases the servers are stored in a secured, climate controlled environment to eliminate overheating of the servers and maintain their security Flexible Control Room Designs Matko Papic, Chief Technology Officer of Evans Consoles, says the transition from bulky CRT equipment to flat-screen (lower profile) monitors was a major disruption in control room design; it changed the whole dynamic. Another evolution is the use of IP video streaming, which allows more flexibility in manipulation of audio-video content, and requires more flexible control room designs. Another shift, driven by larger, higher-definition monitors, is a shift to fewer monitors that display more information. Instead of a smaller monitor for each information stream, larger monitors now consolidate that information into “dashboard” displays. Looking ahead, control rooms will need to be more flexible, both in the initial design and the ability to adapt to changing technology, says Papic. Legacy customers who are currently using PCs may be moving to more remote applications. Sit-stand equipment will continue to be increasingly prevalent. “There will be more emphasis on flexibility, technology integration, and the ability to change over the life of the system,” says Papic. Consolidation Of Multiple Operations Into A Single System A trend in security is consolidation of multiple physical operations into a single system, says Papic. As a result, more customers are taking more interest in alarm management and situational awareness. How is the technology being used in terms of alarm triggers? How can the systems react rapidly and provide information to a larger audience in the control room? These questions impact how control rooms are designed, and Evans Consoles can adapt lessons learned from other markets to these trends in the security arena. Greater use of technology is inevitable, says Coleman of AFC Industries. “It is virtually impossible for humans to monitor all security data at the street level in our cities,” he says. “As computers become more powerful and their programs more all-encompassing, we will see a greater shift to robotic and technology uses that will provide enhanced monitoring capabilities and safety reactions.” Read our Control Rooms series here
Selecting the optimum power supply for a system is critical to an installation When it comes to selecting power supplies, knowledge is power. Determining the power requirements of every systems product, taking into account their integration with one another is critical to ensure that you are selecting and installing the power solutions most appropriate for your installation. Such information will enable you to select the power supplies that will be required to keep your security system running efficiently in the long run. Paul Rizzuto, Technical Sales Manager, Altronix Corp outlines some of the key factors to consider when choosing the right power solution for security installations - including those of video surveillance systems and access control systems - and fire alarm systems. Questions to consider when selecting the optimum power supply Before commencing the evaluation and selection process, three fundamental questions/issues need be addressed:Approvals and conformance to norms: Are there any specific agency approvals that the installation must conform to?Each state, county and even municipality has their own requirements regarding agency approvals. There are a variety of compliance issues such as UL listings for video, access control and fire/life safety that need to be adhered to along with specific local codes. It's imperative that you check with the local AHJ (Authority Having Jurisdiction) to find out what agency listings you must conform to during the design process to assure your security system is in compliance before installing any components and power supplies. Features required: What are the application specific features required for the installation? Selecting power supplies for a security or fire alarm system is a complex process due to a number of variables Before starting the design process, a comprehensive analysis of the facility's security systems are required to determine feature sets of the power supplies. Up until recently, selecting power supplies often required the need to combine various components to deliver the functionality desired. For example, does the system need battery back-up in case of a power failure? All that has changed with the introduction of a new breed of integrated power solutions that deliver both cost and installation advantages. Quantity, location and power requirements of the security system componentsWhat is the number of devices in the system, the power requirements for each, and their physical location?This information is necessary to determine the size and quantity of the power supplies, how many security devices they will run, and where they will be physically located. It is always a good rule of thumb to add 20% more power to your calculations as a safety factor. Alarm signal generation is a key consideration when dealing with power consumption in fire alarms systems Dealing with power consumption issues in fire alarm systems Power consumption is a primary issue when configuring fire alarm systems. One of the most critical considerations revolves around how alarm signals are activated. When an alarm condition exists, Notification Appliance Circuits (NAC) are output from the Fire Alarm Control Panel (FACP) to activate notification appliances such as strobes and horns commonly used to indicate an emergency situation. The number of notification appliances to be activated, along with the current draw for each device and its distance from the FACP, sometimes makes the deployment of NAC Power Extenders a necessary system component. For example, in large commercial installations or multi-tenant buildings, the total current draw of the notification appliances may well exceed the power output of the FACP. In these instances, one or more NAC Power Extenders need to be installed for those notification appliances where the wire runs are too long for the FACP to deliver sufficient power. Features to consider when selecting a NAC Power Extender: Number of Class A or Class B indicating circuits.Total power rating (ex. 6.5 amp, 8 amp or 10 amp).Number of Aux. power outputs with or without battery backup.Programmable outputs: SynchronizationTemporal Code 3Input to output follower mode.Enclosure capacity: Room for battery backupAmple knockouts and room for wiringAgency approvals UL, MEA, CSFM and FM.NAC Power Extenders are available with programmable features that maintain horn/strobe synchronization by either producing internally generated sync protocols utilized by major signal manufacturers, or by electronically repeating these sync protocols from the FACP outputs. Power supply requirements for access control systems - key standards to follow To ensure safety any device designated to lock or unlock an exit must be connected to the fire alarm systemAccess control systems manage entry and exit points at a facility by means of controlled locking devices. NFPA (National Fire Protection Association) requires that any device or system intended to actuate the locking or unlocking of exits, must be connected to the facility's fire alarm system so that all doors will release when an alarm signal is generated.To comply with NFPA requirements, there are two classifications of locking devices that need to be addressed: Fail-Safe and Fail-Secure. Fail-Safe locking devices such as magnetic locks release when they lose power. Fail-Secure locking devices such as electric strikes unlock when power is applied and may be manually released from inside a secured area. This determines the manner in which your power solution removes or provides power and the sequence and timing of each action.Access control power supplies come in both AC and DC versions and some provide multiple voltages simultaneously. Features include independently trigger controlled Fail-Safe/Fail-Secure outputs, power supervision, battery charging and fire alarm interface. Wall and rack mount models are also available.To comply with NFPA requirements, there are two classifications of locking devices that need to be addressed: Fail-Safe and Fail-Secure Some systems may also require the installation of panic hardware devices. Upon activation, the devices' high current power demand can reach up to 16amps, but not all power supplies can handle these high inrush currents. As a result, you need to specify a power supply designed for this type of application. Some operate a single panic hardware device and require optional modules to add features like timing functions, output relays, fire alarm disconnect, or power for additional panic hardware devices. Therefore, these "base" models almost always require additional modules to deliver the functionality you need and may not be cost effective. More advanced models offer integrated features and supply a comprehensive solution. In addition to the convenience of these integrated devices, they are highly cost efficient with respect to total cost of ownership and installation. Video surveillance systems - typical power consumption guidelinesVideo surveillance systems typically run 24/7/365 placing high demands on power supplies. These video power supplies need to deliver a clean and consistent source of 24VAC or 12VDC power to assure uninterrupted operation. Depending on the video component's specific power requirements and its location, there is a wide selection of power supplies to select from. They can be wall or rack mounted, designed for use indoors or outdoors, and feature AC or DC outputs. Configurations typically range from 1 to 32 outputs and some models offer additional features like 115 or 230VAC input with current ratings as high as 25 amps, power LED indicators, and PTC or fused protected outputs. Certain models provide both 24VAC and 12VDC to power both types of surveillance cameras simultaneously. Environmental conditions can affect the performance of video components and the power supply when situated outdoors A few additional variables to consider when selecting video surveillance power supplies include: Environmental conditions: Temperature differences due to change of seasons, day or night, can often be extreme and can have a direct affect on the performance of both the video components and the power supply when located outdoors. Enclosures for outdoor power supplies should be rated to withstand the elements.Ground Isolation: In some cases, the surveillance cameras are not equipped with internal electrical isolation. Should this be the case, it's important to specify a power supply with this feature. Video Transmission Systems: For years, the use of structured cable has been an inexpensive method for transmitting video and data between head end equipment and camera systems. The introduction of UTP transceiver hubs with integral camera power make it possible to transmit both video and data via structured cable along with the power needed for the cameras. This is accomplished via video balun/combiners which pass the power and data to the camera and send the video back to the head end equipment. New highly versatile devices with integral power provide system designers with a highly integrated solution. This new breed of integrated device greatly reduces the time and expense of configuring and installing separate components while helping to minimize bandwidth requirements for large security systems. Paul RizzutoTechnical Sales Manager Altronix Corp
