LILIN SP3034N 600TVL Indoor Speed Dome Camera
Technical Specification
| Make | LILIN |
|---|---|
| Manufacturer | LILIN |
| Category | Video Surveillance>Dome cameras |
| Model code | SP3034N |
| Chip Inch Size | 1/4 |
| Color Type | Color / Monochrome |
| Resolution TVL | 600 |
| Dome Type | PTZ |
| Sensitivity lux | 0.06 |
| Pan Speed o/ sec | 0.5 ~ 90 |
| Tilt Speed o/ sec | 0.5 ~ 90 |
| Indoor/Outdoor | Indoor |
| Digital (DSP) | Yes |
| Electrical Specifications |
Voltage: 24 V AC Power Consumption: 8.5W |
| Focal length | 2.8 ~ 7.3mm |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | 1/60s ~ 1/100,000s |
| S/ N (Signal/ Noise) Ratio dB | >50 |
| Synchronisation | Internal |
| Signal Mode | NTSC |
| Video Output | CVBS 1.0 Vp-p/75 ohmBNC |
| Zoom Ratio | x2.6 |
| Network Properties | Control: PTZ |
| Physical Specifications |
Dimensions mm: 164 x 135 Weight g: 1,050 |
| Environmental Specifications |
Operating Temp oC: -10 ~ +50 C (14 ~ 122 F) Operating Humidity %: 0 ~ 90 |
| Additional info | LILIN SP3034N is a 600TVL indoor speed dome camera featuring 2.6X optical zoom lens, auto focus lens, horizontal flip function, and multi-protocol. |
