Lilin IPR2522ES6 1080P Day & Night Fixed IR IP Dome Camera

Technical Specification

Features:

Make: LILIN
Model code: IPR2522ES6
Chip Inch Size: 1/2.7
Color Type: Color / Monochrome
Resolution TVL: 1080P

Additional info:

Full HD 2 megapixel CMOS image sensor True H.264 AVC/MPEG-4 part 10 real-time video compression H.264 and Motion JPEG multi-profile video streaming 3D noise reduction (MCTF) 2D WDR function Digital PTZ supported Face / Tampering / Audio / Motion detection alarm function Built-in highly sensitive microphone High efficiency IR LED, radiant distance up to 10m Day & Night (IR cut removable) 2-way audio supported Digital I/O : 1 in, 1 out ONVIF supported

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	Video Surveillance>IP Dome cameras
Model code	IPR2522ES6
Chip Inch Size	1/2.7
Color Type	Color / Monochrome
Resolution TVL	1080P
HD	Yes
Megapixel	Yes
Sensitivity lux	0 ~ 0.1
Indoor/Outdoor	Indoor/Outdoor
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 7.5W
Compression	H.264 , Motion JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/30(1/25)s〜1/8000s
Network Properties	Interface: 10/100 Mbps Base-T (Tx), RJ-45 Network Protocols: IPv4, IPv6, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SNMP, SIP, Bonjour Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: Ø100 × 85 Weight g: 280
Environmental Specifications	Operating Temp ^oC: -25 ~ +50 C (-13 ~ +122 F)
System Requirements	Operating System: Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8 Web Browser: Microsoft® Internet Explorer® 6 and later
Additional info	Full HD 2 megapixel CMOS image sensor True H.264 AVC/MPEG-4 part 10 real-time video compression H.264 and Motion JPEG multi-profile video streaming 3D noise reduction (MCTF) 2D WDR function Digital PTZ supported Face / Tampering / Audio / Motion detection alarm function Built-in highly sensitive microphone High efficiency IR LED, radiant distance up to 10m Day & Night (IR cut removable) 2-way audio supported Digital I/O : 1 in, 1 out ONVIF supported
Download PDF version Download PDF version
