Illustra IFS02P6ONWITA Flex 2MP Outdoor PTZ Camera

Technical Specification

Features:
  • Make: Illustra
  • Model code: IFS02P6ONWITA
  • Chip Inch Size: 1/3
  • Color Type: True Day / Night
  • Resolution TVL: 2MP
Read more
Additional info:

2MP resolution for HD quality images • True Day/Night and True Wide Dynamic Range produce quality video regardless of lighting conditions Operating temperature for Flex IR PTZ outdoor model sustains as low as -58°F and up to 140°F for installation into a variety of environments  IP66 (weather) and IK10 (vandal) rated*  ONVIF Profile S conformant for simplified integrations with a variety of manufacturers

Read more
Make Illustra
Manufacturer Tyco Security Products
Model code IFS02P6ONWITA
Chip Inch Size 1/3
Color Type True Day / Night
Resolution TVL 2MP
HD Yes
Megapixel Yes
Dome Type PTZ
Sensitivity lux 0.001 ~ 0.2
Pan Speed o/ sec 0.1 ~ 240
Digital (DSP) Yes
Tilt Speed o/ sec 0.1 ~ 160
Indoor/Outdoor Outdoor
Electrical Specifications Voltage: 24 V AC
Power Consumption: 51 W
Focal length 4.3 ~ 129mm
Compression H.264, H.264+, H.265, MJPEG
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/30(25) ~ 1/30,000 sec
Signal Mode NTSC, PAL
Built-in IR LED Yes
Zoom Ratio x30
Network Properties Interface: IEEE 802.3, 10/100 Base-T Ethernet, Female RJ45
Network Protocols: TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WS-Addressing, CIFS, SNMP, UPNP, RTSP, LLDP
Image Frame Rate: 60 ips
Physical Specifications Dimensions mm: 190 x 330
Weight g: 5,200
Environmental Specifications Operating Temp oC: -50 ~ +60 C (-58 ~ +122 F)
Operating Humidity %: 0 ~ 90
Protection: IP66, IK10
System Requirments Web Browser: IE 9 or above, Firefox, Chrome, Safar
Additional info
  • 2MP resolution for HD quality images •
  • True Day/Night and True Wide Dynamic Range produce quality video regardless of lighting conditions
  • Operating temperature for Flex IR PTZ outdoor model sustains as low as -58°F and up to 140°F for installation into a variety of environments
  • IP66 (weather) and IK10 (vandal) rated*
  • ONVIF Profile S conformant for simplified integrations with a variety of manufacturers
Download PDF version Download PDF version
