IDIS DR-2204P 4-channel Full HD Network Video Recorder

Technical Specification

Features:
  • Make: IDIS
  • Model code: DR-2204P
  • Recording Mode: Real Time / Timelapse / Event
  • Video inputs: 4
  • Hardware solution: Yes
Read more
Additional info:

Total Incoming throughput 84Mbps Up to 120ips Full HD real-time recording Up to 120ips live display Built-in 4 channel PoE switch Supports third party cameras

Read more
Make IDIS
Manufacturer IDIS
Model code DR-2204P
Recording Mode Real Time / Timelapse / Event
Video inputs 4
Hardware solution Yes
Inbuilt multiplexer Yes
Type of multiplexer functions Recording, Playback, Viewing, Network Configuration
Recording system HDD
Storage capacity 24 TB
Secondary storage USB
Resolution 1920 x 1200
Alarm Handling 4 in, 1 out
Video motion detection Yes
Multiple client support Yes
Operating system Linux
Voltage 12 V DC
Power consumption (W) 25.2
Weight (kg) 2.6
Dimensions (mm) 300 x 62 x 231
Operating temperature (°C) 0 ~ 40 C (32 ~ 104 F)
Operating humidity (%) 0 ~ 90
Additional info
  • Total Incoming throughput 84Mbps
  • Up to 120ips Full HD real-time recording
  • Up to 120ips live display
  • Built-in 4 channel PoE switch
  • Supports third party cameras
