Honeywell Security HC35TB5R1JT07 35 Series Bi-Spectrum Thermal Bullet Cameras With 7 Mm Thermal Lens
Technical Specification
- Make: Honeywell Security
- Model code: HC35TB5R1JT07
- Chip Inch Size: 1/2.7
- Color Type: Color / Monochrome
- Resolution: 5MP
Advanced BiSpectrum Technology: Incorporates both thermal and optical sensors in one compact camera unit to provide both heat-signature detection and exceptional image clarity and accuracy for earlier detection at longer distances even when obscured by heavy fog or smoke Extended Distance Detection: Range from 143 meters (469.16 ft) up to 894 meters (2,9323.07 ft) for HC35TB5R1JT07 and from 143 meters (469.16 ft) to 1,278 meters (4,192.91 ft) for the HC35TB5R4JT10 to detect potential threats earlier and from further away Advanced Video Analytics: Identifies living beings and objects that generate a heat signature (vehicles, equipment) and can detect heat, smoke/flame, fire spots, plus line crossing, double line crossing, and wrong way detection for vehicles Reduced False Alarms: Bi-spectral noise filtering algorithms improve accuracy by filtering out noise more effectively, therefore focusing on genuine changes in the scene and minimizing false triggers and alarms Preventative Maintenance: Monitor heat-signature temperatures for early signs of overheating, sparking or mechanical stress so that preventative maintenance can be scheduled - thus serving multiple roles in industrial safety and security Potential Applications:- Commercial and retail building intruder detection/break ins- Fence line and door intrusion,- Server and computer room monitoring,- Electric car charging station monitoring and more
Read more| Make | Honeywell Security |
|---|---|
| Manufacturer | Honeywell |
| Category | Video Surveillance>IP cameras |
| Model code | HC35TB5R1JT07 |
| Chip Inch Size | 1/2.7 |
| Color Type | Color / Monochrome |
| Resolution | 5MP |
| Specialist Type | Thermal |
| Sensitivity Lux | Color: 0.03 Lux @(F2.0, 30 IRE), B/W: 0.003 Lux @(F2.0, 30 IRE), 0 Lux with IR |
| Electrical Specifications |
Voltage: 12 V DC / 24 V DC / PoE Power Consumption: Max. 11 W |
| Motion Activated | Yes |
| Focal Length mm | 7 mm (Thermal) |
| Wide Dynamic Range | Yes |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter Range | 1/5 ~ 1/20,000 s |
| S/ N (Signal/ Noise) Ratio dB | > 55 dB |
| Signal Mode | NTSC, PAL |
| Compression Type | H.265 / H.264 / MJPEG, Smart Codec |
| Network Properties |
Interface: 10 Base-T/100 Base-TX Ethernet (RJ-45) Network Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS, FTP/SFTP, Bonjour |
| Physical Specifications |
Dimensions mm: 275.4 ~ 305.4 x 120.5 x 122.7 Weight g: 1440 |
| Environmental Specifications |
Operating Temperature oC: -40 ~ +60 C (-40 ~ +140 F) Protection: IP66, IP67, IK10 Operating Humidity %: 0 ~ 90 |
| System Requirements | Web Browser: Microsoft Edge, Chrome |
Product description
Honeywell Security introduces the HC35TB5R1JT07 Bi-Spectrum Thermal Bullet Camera—a cutting-edge solution in sophisticated surveillance. Designed for professionals seeking superior security measures, the HC35TB5R1JT07 combines advanced thermal imaging with high-definition optical capabilities to detect heat signatures and capture detailed visual images simultaneously. This model addresses the need for robust security in challenging lighting and environmental conditions.
Enhanced Detection and Recognition
- Outstanding image clarity with 5MP optical resolution and a 256 x 192 thermal sensor.
- Optimize range with various lens options based on installation requirements.
- Extended detection distances—optical recognition up to 28.6 m and thermal up to 104 m.
Intelligent Surveillance
- Advanced analytics detect living beings, overheating equipment, and open flames.
- Vehicle detection capabilities, including line crossing and wrong way alerts.
Increased Operational Efficiency
- Continuous 24/7 monitoring in any weather or lighting condition.
- Durability backed by IP67, IP66, and IK10 ratings.
- Bi-spectral noise reduction for decreased false alarms.
Ideal Use Cases
Perfect for commercial and enterprise settings including perimeter security, electric car station monitoring, and server rooms. With NDAA compliance and robust construction, this camera excels in diverse applications requiring stringent security protocols.
