Hikvision iDS-7232HQHI-M2/S 32 Channel 1080p 1U H.265 Digital Video Recorder

Technical Specification

This product model is not available in this region

Hikvision iDS-7232HQHI-M2/S 32 Channel 1080p 1U H.265 Digital Video Recorder

Features:

Make: Hikvision
Model code: iDS-7232HQHI-M2/S
Series: AcuSense Series
Channels: 32
Hybrid IP inputs: 2-ch (up to 34-ch); Enhanced IP mode on: 8-ch (up to 40-ch)

Additional info:

Deep learning-based motion detection 2.0 for all analog channels Deep learning-based perimeter protection H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression HDTVI/AHD/CVI/CVBS/IP video inputs Audio via coaxial cable Up to 40-ch IP camera inputs (up to 8 MP) Up to 10 TB capacity per HDD Encoding up to 1080p @ 15 fps 2 SATA interfaces

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Hikvision
Manufacturer	Hikvision USA Inc.
Category	Video Surveillance>Digital video recorders (DVRs)
Model code	iDS-7232HQHI-M2/S
Series	AcuSense Series
Channels	32
Hybrid IP inputs	2-ch (up to 34-ch); Enhanced IP mode on: 8-ch (up to 40-ch)
Recording Mode	Real Time / Timelapse / Event
Inbuilt Multiplexer	Yes
Storage Capacity GB	10,240
Image per second (IPS)	Main Stream : 15, 25 (P) / 30 (N); Sub Stream : 12, 25 (P) / 30 (N)
Compression Type	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Resolution	1080p
Signal Mode	PAL / NTSC
External Storage	USB
Audio Recording and Properties	G.711u, 1-ch input, RCA (2.0 Vpp, 1 KΩ); 1-ch output, RCA (Linear, 1 KΩ)
Recording System	HDD
Type of Multiplexer Functions	Recording, Playback
IP Storage rate (fps)	Main Stream : 15, 25 (P) / 30 (N); Sub Stream : 12, 25 (P) / 30 (N)
Physical Specifications	Dimensions mm: 380 x 320 x 48 Weight kg: < 2.1
Electrical Specifications	Voltage: 12 V DC Power Consumption: < 40 W
Environmental Specifications	Operating Temp ^oC: -10 ~ 55 C (14 ~ 131 F) Operating Humidity %: 10 ~ 90
Additional info	Deep learning-based motion detection 2.0 for all analog channels Deep learning-based perimeter protection H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression HDTVI/AHD/CVI/CVBS/IP video inputs Audio via coaxial cable Up to 40-ch IP camera inputs (up to 8 MP) Up to 10 TB capacity per HDD Encoding up to 1080p @ 15 fps 2 SATA interfaces
