Hikvision DS-7216HUHI-F2/S 16-Channel Turbo HD DVR

Technical Specification

Features:
  • Make: Hikvision
  • Model code: DS-7216HUHI-F2/S
  • Series: Explosion Proof
  • Channels: 16
  • Recording Mode: Event
Read more
Additional info:

H.264+ & Dual-stream video compression Support HD-TVI/analog/AHD/IP camera triple hybrid Support both HD-TVI and analog cameras with adaptive access Full channel@5MP resolution non-real-time recording HDMI output at up to 4K while VGA output at up to 1920×1080P resolution Long transmission distance over coax cable

Read more
Make Hikvision
Manufacturer Hikvision USA Inc.
Model code DS-7216HUHI-F2/S
Series Explosion Proof
Channels 16
Recording Mode Event
Alarm I/O 16 in, 4 out
Storage Capacity GB 6000
Compression Type H.264+, H.264
Resolution 3840 x 2160
Signal Mode PAL / NTSC
External Storage USB
Audio Recording and Properties G.711u
Recording System HDD
Type of Multiplexer Functions Playback
IP Ready Yes
Physical Specifications Dimensions mm: 380 x 320 x 48
Weight kg: < 2
Electrical Specifications Voltage: 12 V DC
Power Consumption: < 25 W
Environmental Specifications Operating Temp oC: -10 ~ +55 C (14 ~ 131 F)
Operating Humidity %: 10 ~ 90
Additional info
  • H.264+ & Dual-stream video compression
  • Support HD-TVI/analog/AHD/IP camera triple hybrid
  • Support both HD-TVI and analog cameras with adaptive access
  • Full channel@5MP resolution non-real-time recording
  • HDMI output at up to 4K while VGA output at up to 1920×1080P resolution
  • Long transmission distance over coax cable
