eneo IPD-72A0003M0B Network Dome, Fixed

Technical Specification

Features:
  • Make: eneo
  • Model code: IPD-72A0003M0B
  • Chip Inch Size: 1/3
  • Color Type: True Day / Night
  • Resolution TVL: 1080p
Read more
Additional info:

1/2,8" Sony STARVIS CMOS Resolution max. 1920x1080 (Full HD) Optical 3x Auto Focus Zoom, 16x Digital 3~9 mm day&night zoom lens, IR cut filter VerticalView 90°/270° mode only H.264, HTML5 Playback DOL-WDR by triple scan images at 30/25fps VCA Video Analytic, ONVIF Event Mapping Cross Web Browsing (IE, Safari, Firefox, Chrome) Responsive Web Design, Zero configuration Triple Streaming: 2x H.264, 1x MJPEG Slot for Micro SD card ONVIF conformity, PoE IEEE802.af

Read more
Make eneo
Manufacturer eneo
Model code IPD-72A0003M0B
Chip Inch Size 1/3
Color Type True Day / Night
Resolution TVL 1080p
HD Yes
Dome Type Static
Sensitivity lux 0.1
Indoor/Outdoor Indoor/Outdoor
Mount Type Wall, Ceiling
Electrical Specifications Voltage: 12 V DC / 24 V AC / PoE
Power Consumption: 9.8 W
Focal length 3.2 ~ 9 mm
Compression H.264, M-JPEG
Back Light Compensation Yes
White Balance Yes
Electronic Shutter range 1/25 ~ 1/60.000sec.
S/ N (Signal/ Noise) Ratio dB 50
Network Properties Interface: 10Base-T, 100Base-TX
Network Protocols: TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour
Image Frame Rate: 25 ~ 30 fps
Physical Specifications Dimensions mm: 72 x 74 x 125
Weight g: 450
Environmental Specifications Operating Temp oC: -50 ~ +50 C (-58 ~ +122 F)
Protection: IP67, IK10
System Requirments Web Browser: MS internet Explorer: ActiveX ex 9.0, Safari: MJPEG, Mozilla: MJPEG, Google Chrome: MJPEG, Edge: MJPEG
Additional info
  • 1/2,8" Sony STARVIS CMOS
  • Resolution max. 1920x1080 (Full HD)
  • Optical 3x Auto Focus Zoom, 16x Digital
  • 3~9 mm day&night zoom lens, IR cut filter
  • VerticalView 90°/270° mode only H.264, HTML5 Playback
  • DOL-WDR by triple scan images at 30/25fps
  • VCA Video Analytic, ONVIF Event Mapping
  • Cross Web Browsing (IE, Safari, Firefox, Chrome)
  • Responsive Web Design, Zero configuration
  • Triple Streaming: 2x H.264, 1x MJPEG
  • Slot for Micro SD card
  • ONVIF conformity, PoE IEEE802.af
Download PDF version
