Dedicated Micros DM/CMVUVRD720 IP Dome camera

Technical Specification

Features:

Make: Dedicated Micros
Model code: DM/CMVUVRD720
Series: CamVu720 Series
Chip Inch Size: 1/3
Color Type: Color / Monochrome

Additional info:

1x audio input (mono) – 3.5mm jack, 47kΩinput impedance, 1x audio ouput (mono) – 3.5mm jack, 47kΩinput impedance. Video motion detection (VMD) & activity detection, zoned alarms based on multiple inputs. On alarm actions include; alarm reporting, record profile change, email, relay closure (relay closure on models with relay outputs only). * ICMP, DNS, NTP, TCP, UPP, UDP, ARP, RTP, Telnet, FTP, AoE, SNMP, ZeroConf.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Dedicated Micros
Manufacturer	Dedicated Micros
Category	Video Surveillance>IP Dome cameras
Model code	DM/CMVUVRD720
Series	CamVu720 Series
Chip Inch Size	1/3
Color Type	Color / Monochrome
Resolution TVL	720
HD	Yes
Dome Type	Variable Focus
Sensitivity lux	0.3 @ F1.3
Mount Type	Surface
Electrical Specifications	Voltage: 12-24 Vdc Power Consumption: 4.5 W
Focal length	2.8 ~ 10
Compression	JPEG, H.264, MPEG-4
Signal Mode	PAL, NTSC
Network Properties	Interface: Ethernet: 10/100 BaseT RJ45 Connector PoE Network Protocols: DCCP, DHCP, HTTP, HTTPS, IPv4, SMTP, Bonjour* Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: 148 x 148 x 104 Weight g: 1,180
Environmental Specifications	Operating Temp ^oC: -10 ~ +50 Operating Humidity %: 20 ~ 80 Protection: IP66, Vandal Resistant
Additional info	1x audio input (mono) – 3.5mm jack, 47kΩinput impedance, 1x audio ouput (mono) – 3.5mm jack, 47kΩinput impedance. Video motion detection (VMD) & activity detection, zoned alarms based on multiple inputs. On alarm actions include; alarm reporting, record profile change, email, relay closure (relay closure on models with relay outputs only). * ICMP, DNS, NTP, TCP, UPP, UDP, ARP, RTP, Telnet, FTP, AoE, SNMP, ZeroConf.
Download PDF version Download PDF version
