Dallmeier Panomera S7/8 Topline UWDR Day/Night IP Camera

Technical Specification

Features:

Make: Dallmeier
Model code: Panomera S7/8 Topline
Color Type: Color / Monochrome
Digital (DSP): Yes
Specialist Type: Megapixel

Additional info:

Dallmeier Panomera S7/8 Topline is a multifocal sensor system with 7/8 sensors. The camera is 4K Ultra HD Ready and features Ultra Wide Dynamic Range (UWDR) for highest color fidelity and detail reproduction even in scenes with a wide range of contrast and strong backlighting. The day/night IP camera also features bandwidth-friendly real-time data transmission (streaming) with up to 30fps at full resolution. It also supports ONVIF Profile S compliance for easy integration into 3rd party systems. It is suitable for indoor and outdoor applications.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Dallmeier
Manufacturer	Dallmeier electronic USA, Inc.
Category	Video Surveillance>IP cameras
Model code	Panomera S7/8 Topline
Color Type	Color / Monochrome
Digital (DSP)	Yes
Specialist Type	Megapixel
Sensitivity Lux	0.01
Auto Iris	Yes
Direct Drive	Yes
Electrical Specifications	Voltage: 48 V DC, 24 V AC Power Consumption: 60 W
Wide Dynamic Range	Yes
Network Properties	Image Frame Rate: 30 fps Network Protocols: IPv4, TCP, UDP, ARP, ICMP, DHCP, NTP, HTTP, RTSP, IGMP V2, FTP, SMTP, RTP, RTCP
Auto Gain Control	Yes
White Balance	Yes
Compression Type	H.264
Environmental Specifications	Protection: IP66 Operating Temperature ^oC: -40 ~ +50 C (-40 ~ +122 F) Operating Humidity %: 0 ~ 90
HD	Yes
Additional info	Dallmeier Panomera S7/8 Topline is a multifocal sensor system with 7/8 sensors. The camera is 4K Ultra HD Ready and features Ultra Wide Dynamic Range (UWDR) for highest color fidelity and detail reproduction even in scenes with a wide range of contrast and strong backlighting. The day/night IP camera also features bandwidth-friendly real-time data transmission (streaming) with up to 30fps at full resolution. It also supports ONVIF Profile S compliance for easy integration into 3rd party systems. It is suitable for indoor and outdoor applications.
