Dahua Technology N25CL5Z 2MP IR Starlight Vari-focal EPoE Dome

Technical Specification

Features:
  • Make: Dahua Technology
  • Model code: N25CL5Z
  • Chip Inch Size: 1/3
  • Color Type: True Day / Night
  • Resolution TVL: 2MP
Read more
Additional info:

1/2.8-in. 2 MP Progressive-scan STARVIS™ CMOS Sensor Triple Stream Encoding Smart H. 265+ and H.264 Dual Codecs 2 MP at 60 fps Maximum Resolution 2.7 mm to 13.5 mm Motorized Optical Zoom Lens Enhanced Power and Data Transmission Distances with ePoE Enhanced Starlight Technology True WDR (120 dB) and True Day/Night (ICR) Maximum IR LED Length 50 m (164 ft) with Smart IR IP67 Ingress Protection and IK10 Vandal Resistance Intelligent Video System Five-year Warranty (for products sold through an authorized Dahua Dealer)

Read more
Make Dahua Technology
Manufacturer Dahua Technology USA Inc.
Model code N25CL5Z
Chip Inch Size 1/3
Color Type True Day / Night
Resolution TVL 2MP
Megapixel Yes
Sensitivity lux 0 ~ 0.05
Digital (DSP) Yes
Indoor/Outdoor Outdoor
Mount Type ceiling, wall, pole
Electrical Specifications Voltage: 12 V DC / 24 V AC / PoE+
Power Consumption: < 15 W
Focal length 2.7 ~ 13.5 mm
Compression Smart H.265+, H.265, Smart H.264+, H.264
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/3 s to 1/100,000 s
S/ N (Signal/ Noise) Ratio dB > 50
Network Properties Interface: RJ-45 (10/100 Base-T)
Network Protocols: HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP, SNMP
Image Frame Rate: 60 fps
Physical Specifications Dimensions mm: ø159 x 118
Weight g: 950
Environmental Specifications Operating Temp oC: -30 ~ +60 C (-22 ~ +140 F)
Operating Humidity %: < 95
Additional info
  • 1/2.8-in. 2 MP Progressive-scan STARVIS™ CMOS Sensor
  • Triple Stream Encoding
  • Smart H. 265+ and H.264 Dual Codecs
  • 2 MP at 60 fps Maximum Resolution
  • 2.7 mm to 13.5 mm Motorized Optical Zoom Lens
  • Enhanced Power and Data Transmission Distances with ePoE
  • Enhanced Starlight Technology
  • True WDR (120 dB) and True Day/Night (ICR)
  • Maximum IR LED Length 50 m (164 ft) with Smart IR
  • IP67 Ingress Protection and IK10 Vandal Resistance
  • Intelligent Video System
  • Five-year Warranty (for products sold through an authorized Dahua Dealer)
Download PDF version Download PDF version
