Dahua Technology HCVR8208/16A-S3 8/16 Channel 1080P 1U Digital Video Recorder
Technical Specification
Features:
- Make: Dahua Technology
- Model code: HCVR8208/16A-S3
- Series: Ultra series
- Channels: 8/16
- Recording Mode: Real Time / Timelapse / Event
Additional info:
Embedded processor H.264+/H.264 video compression Support HDCVI/AHD/CVBS video inputs Max 64 channels IP camera inputs, each channel up to 12MP Max 256Mbps Incoming Bandwidth Smart Search and Intelligent Video System
Read more| Make | Dahua Technology |
|---|---|
| Manufacturer | Dahua Technology USA Inc. |
| Category | Video Surveillance>Digital video recorders (DVRs) |
| Model code | HCVR8208/16A-S3 |
| Series | Ultra series |
| Channels | 8/16 |
| Recording Mode | Real Time / Timelapse / Event |
| Hybrid IP inputs | 16 |
| Inbuilt Multiplexer | Yes |
| Alarm I/O | 8/16 |
| Storage Capacity GB | 8TB |
| Image per second (IPS) | 25 ~ 30 fps |
| Compression Type | H.264+, H.264 |
| Resolution | 3840 x 2160 |
| External Storage | USB |
| Recording System | HDD |
| Color Type | color |
| IP Storage rate (fps) | 25 ~ 30 |
| Type of Multiplexer Functions | Simulatneous Live, Recording, Playback |
| Network Type | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| IP Ready | IP |
| Physical Specifications |
Dimensions mm: 375 x 310 x 5 Weight kg: 2.35 |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: 40 W |
| Environmental Specifications |
Operating Temp oC: -10 ~ +55 C (+14 ~ +131F) Operating Humidity %: 0 ~ 90 |
| Additional info |
|
